ONSEMI MJD2955T4G Power Transistor
The MJD2955PNP and MJD3055NPN are complementary power transistors designed for general purpose amplifier and low-speed switching applications. Packaged in DPAK for surface-mount applications, these transistors feature lead formed in plastic sleeves, high current gain, and UL 94 V-0 epoxy. They operate within temperature ranges of -85°C to +150°C, with maximum collector-emitter voltage of 60 V and collector current of 10 A. Ideal for high current and voltage switching, their robust thermal and electrical characteristics make them suitable for automotive and industrial environments, offering reliable performance with Pb-Free and ROHS compliance.
ONSEMI MJD2955T4G Power Transistor Specifications:
- Collector-Emitter Voltage: 60 Vdc
- Collector-Base Voltage: 70 Vdc
- Emitter-Base Voltage: 5 Vdc
- Collector Current: 10 Adc
- Base Current: 6 Adc
- Total Power Dissipation: 20 W @ 25°C, derate 0.16 W/°C
- Operating Temperature Range: -85°C to +150°C
- Thermal Resistance, Junction-to-Case: 6.25°C/W
- Thermal Resistance, Junction-to-Ambient: 71.4°C/W
- Electrically similar to MJE2955 and MJE3055, Pb-Free, RoHS compliant
- Package Types: DPAK, IPAK, with surface mount lead forming
- Mechanical and electrical features suitable for automotive and industrial applications
- ESD Human Body Model: 3B V, machine model Vv
Buy the ON Semiconductor Series Power Transistor: MJD2955T4G
Get the high-performance power transistor from ON Semiconductor in DPAK packaging today. Designed for reliable switching and amplification, it features high current gain and robust thermal capabilities. Suitable for automotive, industrial, and general electronics applications, this Pb-Free and RoHS compliant transistor offers excellent durability and efficiency. Easy to install with surface-mount technology, ensuring optimal system performance. Purchase online now to benefit from fast delivery and quality assurance, and elevate your electronic projects with guaranteed reliability and precision.
Order your ON Semiconductor Series Power Transistor MJD2955T4G today and give your projects the dependable current and voltage handling they deserve.
