ONSEMI NC7SP74K8X CMOS Flip-Flop
The NC7SP74 TinyLogic ULP D-Type Flip-Flop is an ultra-low power CMOS device designed for space-saving surface-mount applications, delivering high-speed data transfer with minimal power. It features a preset and clear function, operates within a voltage range of 0.9V to 3.6V, and is fabricated in a Pb-Free MicroPak package ideal for battery-powered systems. Its advanced CMOS technology ensures fast propagation delays, low static and dynamic power dissipation, making it suitable for portable, energy-efficient devices requiring reliable flip-flop performance.
ONSEMI NC7SP74K8X CMOS Flip-Flop Specifications:
- Package: 8-Lead MicroPak, JEDEC MO-187, Vatiation CA 3.1mm Wide
- Operating Voltage: 0.9V to 3.6V
- Input Voltage Range: OV to 3.6V
- Output Voltage (High/Low): OV to Veg
- Propagation Delay (typical): 20-42.6ns depending on voltage
- Power Dissipation: Ultra low static and dynamic power design
- Current in Low State: 41.0-42.6mA depending on voltage
- Input Capacitance: 20F, Output Capacitance: 40F
- Temperature Range: -40°C to 85°C (commercial)
- Clock Frequency: Up to 150 MHz (maximum depending on conditions)
- Capacitance: 15pF, 30pF, and 45pF typical load conditions
- Tape and Reel Packaging: MicroPak and US8 formats for automated assembly
- Material: Pb-Free CMOS fabrication
- Edge Rate: Minimum input edge rate of 10ns/V at specified voltages
Buy the Fairchild Series TinyLogic ULP D-Type Flip-Flop: NC7SP74K8X
Purchase the Fairchild Series TinyLogic ULP D-Type Flip-Flop NC7SP74K8X online now to ensure your projects benefit from its ultra-low power consumption, fast operation, and space-saving MicroPak package. Ideal for portable devices and energy-efficient systems, this flip-flop features preset and clear functions, operates within a voltage range of 0.9V to 3.6V, and delivers excellent performance with minimal power dissipation. Buy online today to get quick delivery and reliable performance for your electronic applications.
Order your Fairchild Series TinyLogic ULP D-Type Flip-Flop NC7SP74K8X today and enhance your battery-powered designs with reliable, ultra-low power performance.
Frequently Asked Questions
Where can I buy ONSEMI NC7SP74K8X?
You can click on the BUY or RFQ button to purchase NC7SP74K8X from an authorized ONSEMI distributor.
How do I troubleshoot issues or seek technical support for part NC7SP74K8X?
You can download the NC7SP74K8X datasheet or visit the ONSEMI website for support.
Who is the manufacturer of NC7SP74K8X?
ONSEMI
