ONSEMI NCP1117DT50RKG Voltage Regulator Module
The NCP1117 Series is a low dropout positive voltage regulator capable of providing over 1.0 A output current with a maximum dropout voltage of 1.2 V at 800 mA. It features fixed output voltages of 1.5 V, 1.8 V, 1.9 V, 2.0 V, 2.5 V, 2.85 V, 3.3 V, 5.0 V, and 12 V, with no minimum load requirement to maintain regulation. An adjustable version allows programming from 1.25 V to 18.8 V using external resistors. Internal protections include current limiting, thermal shutdown, and safe operating area compensation. Suitable for consumer, industrial, and automotive applications, it operates with input voltages up to 20 V in compact packages.
ONSEMI NCP1117DT50RKG Voltage Regulator Module Specifications:
- Output Current in Excess of 1.0 A
- Maximum Dropout Voltage: 1.2 V at 800 mA
- Fixed Output Voltages: 1.5 V, 1.8 V, 1.9 V, 2.0 V, 2.5 V, 2.85 V, 3.3 V, 5.0 V, 12 V
- Adjustable Output Range: 1.25 V to 18.8 V with external resistors
- Input Voltage: Up to 20 V
- Protection Features: Current limiting, thermal shutdown, safe operating area
- Package Types: SOT-223, DPAK
- Operating Temperature: -40°C to +125°C (NCV series), up to +125°C (NCP series)
- No minimum load requirement for fixed voltages
- On-chip trimming accuracy: ±1%
- Application: Power regulation for consumer electronics, industrial equipment, automotive systems
Buy the ON Semiconductor Series NCP Series 50V Low Dropout Voltage Regulator: NCP1117DT50RKG
Get your ON Semiconductor Series NCP1117 DT50RKG online today for dependable power regulation in industrial, consumer, and automotive electronic devices. With fixed 5.0 V output, high current capacity, and integrated protection features, this compact voltage regulator ensures stable operation under various conditions. Its low dropout voltage and wide input voltage range make it ideal for power supply post regulation and demanding applications requiring reliable performance. Purchase now through our online store and benefit from fast delivery, secure checkout, and expert support to meet your project needs efficiently.
Order your ON Semiconductor Series NCP1117DT50RKG today and ensure reliable power regulation for your industrial and automotive projects.
Frequently Asked Questions
Where can I buy ONSEMI NCP1117DT50RKG?
You can click on the BUY or RFQ button to purchase NCP1117DT50RKG from an authorized ONSEMI distributor.
How do I troubleshoot issues or seek technical support for part NCP1117DT50RKG?
You can download the NCP1117DT50RKG datasheet or visit the ONSEMI website for support.
Who is the manufacturer of NCP1117DT50RKG?
ONSEMI
