ONSEMI NCP1654BD200R2G Load Switch
The NCP334 and NCP335 are high-side P-channel MOSFET power switches designed for efficient load control in portable devices. Operating from 1.2 V to 5.5 V, they feature an ultra-small WLCSP4 package (0.96 x 0.96 mm) and can handle load currents up to 2 A. The NCP335 model includes an automatic discharge path to eliminate residual output voltage. These devices incorporate low Ron on-resistance, active high enable pins, and robust ESD ratings, making them ideal for mobile phones, tablets, cameras, GPS, and other portable electronics requiring compact, reliable power switching solutions.
ONSEMI NCP1654BD200R2G Load Switch Specifications:
- Operating Voltage Range: 1.2 V to 5.5 V
- Load Current: Up to 2 A
- Power MOSFET On Resistance: 38 mΩ at 3.3 V
- Package: WLCSP4, 0.96 x 0.96 mm, 0.5 mm pitch
- Maximum Junction Temperature: 125°C
- Storage Temperature Range: -40°C to +150°C
- ESD Ratings: 4 kV HBM, 2 kV CDM
- Input/Output Capacitors: 1 μF recommended close to pins
- Enable Pin: Active high logic
- Auto-Discharge Path: NMOS MOSFET between OUT and GND (NCP335 only)
- Thermal Resistance: Approx. 100°C/W (WLCSP package)
- Power Dissipation: Up to 0.5 W depending on PCB heat sinking
- Isolation of connected ICs to optimize battery life and minimize leakage currents.
Buy the Buy ON Semiconductor NCP334 Part Number NCP1654BD200R2G Online
Purchase the ON Semiconductor NCP334 load switch online today. This compact, high-current device offers low Ron, auto-discharge, and robust ESD protection, suitable for mobile phones, tablets, cameras, GPS, and portable devices. Its small WLCSP4 package (0.96 x 0.96 mm) allows for easy integration into space-constrained circuits. With a voltage range from 1.2 V to 5.5 V and handling up to 2 A, it ensures optimal power control, reduced leakage, and enhanced device efficiency, streamlining your portable device power management.
Order your ON Semiconductor NCP334 load switch today and ensure reliable power management for your portable and mobile projects with efficient switching capabilities.
Frequently Asked Questions
Where can I buy ONSEMI NCP1654BD200R2G?
You can click on the BUY or RFQ button to purchase NCP1654BD200R2G from an authorized ONSEMI distributor.
How do I troubleshoot issues or seek technical support for part NCP1654BD200R2G?
You can download the NCP1654BD200R2G datasheet or visit the ONSEMI website for support.
Who is the manufacturer of NCP1654BD200R2G?
ONSEMI
