ONSEMI NCP334FCT2G Load Switch
The NCP45520 and NCP45521 are advanced load switches featuring integrated N-channel MOSFETs with low Ron, soft-start control, fault protections, and power good signaling suitable for portable electronics, servers, and industrial equipment. They support voltage ranges from 0.5 V to 13.5 V, include thermal shutdown, undervoltage lockout, short-circuit protection, and load bleed for quick discharge. These compact, cost-effective devices offer configurable enable polarity, controlled slew rate, and are ideal for power management and hot-swap applications demanding low power consumption and high reliability.
ONSEMI NCP334FCT2G Load Switch Specifications:
- Input Voltage Range: 0.5 V to 13.5 V
- On-Resistance (Ron): Typical 95-139 mΩ depending on voltage and device variant
- Continuous MOSFET Current: Up to 78 A
- Thermal Resistance, Junction-to-Ambient: 40.0 °C/W
- Supply Voltage: 3.0 V to 13.5 V
- Power Dissipation: 2.50 W at 25°C
- Thermal Shutdown Threshold: 145 °C with 20 °C hysteresis
- Undervoltage Lockout Threshold: 0.25 V to 0.45 V
- Short-Circuit Protection: Threshold 200-500 mV
- ESD Capability: 3.0 kV Human Body Model
- Operating Temperatures: -40°C to 150°C
- Package: DFN8 2x2, 0.5P
Buy the Buy ON Semiconductor NCP45520 Part Number NCP45520 Online
Experience seamless power management with the ON Semiconductor NCP45520 load switch, offering low Ron, fault protections, thermal shutdown, and load bleed features. Perfect for portable electronics, servers, and industrial systems, this device ensures efficient switching, reduces inrush current with soft start, and provides system safeguard signals like power good. Its compact DFN8 package makes integration straightforward. Available online, it guarantees dependable operation and long-term durability, making it an ideal choice for hot-swap applications and demanding power control scenarios. Purchase now for quick, hassle-free delivery.
Get ON Semiconductor NCP45520 today—designed for reliable power switching with low Ron, fault protection, and quick discharge in compact form.
Frequently Asked Questions
Where can I buy ONSEMI NCP334FCT2G?
You can click on the BUY or RFQ button to purchase NCP334FCT2G from an authorized ONSEMI distributor.
How do I troubleshoot issues or seek technical support for part NCP334FCT2G?
You can download the NCP334FCT2G datasheet or visit the ONSEMI website for support.
Who is the manufacturer of NCP334FCT2G?
ONSEMI
