ONSEMI NTNUS3171PZT5G Small Signal MOSFET
The NTNUS3171PZ is a small signal P-Channel MOSFET ideal for high-speed switching and power management in ultra-thin portable electronics. Featuring a low Rps(on) solution in a compact 1.0 x 0.6 mm SOT-1123 package, it supports a gate voltage rating of 1.5 V and operates with a drain-to-source voltage of 20 V. Its low on-resistance and high current capacity up to 200 mA make it perfect for high side switching and interfacing applications. The device is Pb-free and designed for reliable performance in space-constrained environments, with thermal and electrical characteristics optimized for efficient power handling.
ONSEMI NTNUS3171PZT5G Small Signal MOSFET Specifications:
- Maximum Drain-to-Source Voltage: 20 V
- Gate-to-Source Voltage: ±28 V
- Continuous Drain Current: 150 mA at 25°C, 200 mA at 5s pulsed
- Power Dissipation: 125 mW steady state, 200 mW at 5s pulsed
- Source Current (Body Diode): -200 mA
- Operating Junction Temperature Range: -55°C to +150°C
- Thermal Resistance (Junction to Ambient): 7000 CW (steady state), 600 CW (5s)
- Gate Threshold Voltage: -0.4 to -1.0 V
- On Resistance (Rds(on)): 20 to 55 mΩ at -4.5V Gate-Source voltage
- Capacitances: Ciss 13 pF, Coss 34 pF, Crss 1.6 pF
- Switching Delay Time: 30 ns, Fall Time: 145 ns
- Soldering Lead Temperature: 260°C for 10s
- Package: SOT-1123 (524AA-01), Pb-Free
- Dielectrics include UL 94V-0 compatibility
- Maximum Lead Thickness: Includes Lead Finish
- Surface-mount on FR4 with 2mm, 1 oz Cu pad recommended
