Ohmite HS2568RF Aluminium Housed Resistor
The HS Aluminium Housed Resistor is a robust, high-power resistor designed for direct heatsink mounting with thermal compound, maximizing heat dissipation and performance. Compliant with MIL 18546 and IEC 115 standards, it offers excellent pulse capability across values from ROO5 to 100K, with custom designs available. Features include low inductance, a wide ohmic range, and RoHS compliance. Suitable for demanding applications requiring reliable resistance, these resistors are ideal for industrial environments, offering efficient heat management and durability under high temperatures.
Ohmite HS2568RF Aluminium Housed Resistor Specifications:
- Power Dissipation: Rated from 4W to 300W depending on model, derates linearly at high temperatures to 200°C maximum temperature, ensuring reliability under load
- Resistance Range: From R005 to 100K ohms, suitable for various high pulse and high current applications
- Temperature Coefficient: Typical < 1K 100ppm, > 1K 25ppm, special lower TCRs available upon request
- Insulation Resistance: Minimum 10,000 MΩ in dry conditions, ensuring high electrical isolation
- Physical Dimensions: Vary by model, e.g., HS15, 28.0mm diameter, HS300, 72.5mm diameter, designed for easy heatsink mounting
- Material: Aluminium housing with proprietary heat sink compound, facilitating efficient heat transfer and durability
- Construction: Wound with minimal inductance, available in low inductance versions (NHS series), ensures high pulse capability
- Voltage Ratings: Up to 4500 V AC withstand voltage, rated for peak current and safe operational limits
- Tolerance: Standard +5% (J), +10% (K), with options for tighter tolerances (+1% F, +2% G, +3% H)
- Standards Compliance: RoHS compliant, meeting international environmental and safety requirements
Buy the Arcol Series HS Aluminium Housed Resistor: HS2568RF
Secure your high-power needs with the Arcol HS2568RF aluminium housed resistor. Designed for direct heatsink mounting, it offers excellent thermal management and durability. With a wide resistance range from R005 to 100K ohms, it supports high pulse capabilities and operates reliably under demanding conditions. RoHS compliant, with options for custom designs, this resistor ensures efficient heat dissipation and stable performance in industrial environments. Purchase online today for fast delivery and dependable operation in your electrical and electronic systems.
Buy Arcol HS2568RF aluminium housed resistor now and experience unmatched reliability and performance in high-power industrial applications.
Frequently Asked Questions
Where can I buy Ohmite HS2568RF?
You can click on the BUY or RFQ button to purchase HS2568RF from an authorized Ohmite distributor.
How do I troubleshoot issues or seek technical support for part HS2568RF?
You can download the HS2568RF datasheet or visit the Ohmite website for support.
Who is the manufacturer of HS2568RF?
Ohmite
