OPTO 22 SNAPODC32SNK Digital Output Module
The SNAP-ODC-32-SNK is a digital output module (load sinking) that provides 32 digital output channels within a compact SNAP module. It is ideal for OEMs and applications requiring a high number of digital outputs on a single SNAP I/O rack. The high-density design reduces per-point costs by offering up to eight times more channels in the same space. This module mounts on a SNAP PAC rack alongside other I/O modules and can be used in PC-based control systems or as remote I/O for PLC systems such as Allen-Bradley's MicroLogix, ControlLogix, or CompactLogix. It features 1500V isolation and an output turn-on/turn-off time of approximately 100 microseconds.
OPTO 22 SNAPODC32SNK Digital Output Module Specifications:
- Output channels: 32 channels, grouped in four sets of 8 points
- Output type: Load sinking (negative common connection)
- Switching Voltage: 5-60 VDC
- Nominal Switching Voltage: 12-24 VDC
- Maximum Load per Point: 0.25 A
- Output Leakage: <10 microamps per channel at 60 V, 70°C
- Voltage Drop: 0.15 VDC at 0.25A
- Surge Capability: 1A
- Input Resistance: Not applicable
- Isolation: 1500 V field to logic, group-to-group
- Turn-On Time: 100 microseconds
- Polling Time from I/O processor: 2-30 ms typical
- Operating Temperature: -20 to 70°C
- Storage Temperature: -40 to 85°C
- Dimensions: 3.26 x 3.05 inches (82.80 x 77.47 mm)
- Mounting: Snap rack compatible, uses four 4-40 screws for security
- Certifications: RoHS, CE, UL, FM (models ending in -FM)
- Warranty: Lifetime
Buy the Buy Opto 22 SNAPODC32SNK Digital Output Module Load Sinking 32 Channels Online
Enhance your automation system with the Opto 22 high-density digital output module. Featuring 32 load sinking channels, 1500V isolation, and rapid 100 microsecond switching, this module is perfect for industrial control, OEM, and PLC remote I/O applications. Designed to mount on SNAP PAC racks alongside analog and digital modules, it offers robust performance, efficiency, and proven durability. Simplify wiring with optional breakout boards or direct wiring options, and ensure reliable operation with lifetime warranty support. Order online now for quick deployment.
Get Opto 22 SNAPODC32SNK today—built for high-density digital output control with fast switching times and high reliability.
