Panasonic ECWH12123JV High Voltage Film Capacitor
Panasonic metallized polypropylene film capacitor type ECWH(V) a features non-inductive construction with flame-retardant epoxy resin coating, ideal for high-frequency high-voltage circuits like inverters and resonant systems. It offers low-loss, excellent electrical characteristics, and RoHS compliance. Suitable for applications requiring reliable high voltage operation, these capacitors have rated voltages from 1000 VDC to 2000 VDC, with capacitance ranges from 0.0036 to 0.10 microfarads, and temperature ratings from -40°C to +105°C. They are available with various lead forms and packaging styles for automated insertion and bulk purchasing.
Panasonic ECWH12123JV High Voltage Film Capacitor Specifications:
- Dielectric: Metallized polypropylene
- Rated voltages: 1000 VDC, 1250 VDC, 1600 VDC, 2000 VDC
- Capacitance range: 0.0036 to 0.10 microfarads
- Capacitance tolerance: +3% (H), +5% (J)
- Temperature range: -40°C to +105°C
- Tan δ: 0.1% at 20°C, 1 kHz; 0.2% at 20°C, 10 kHz
- Insulation resistance: ≥30,000 MΩ at 20°C, 500 VDC, 60s
- Dimensions vary with voltage and capacitance, approx. 18.0 mm height
- Lead forms: straight, crimped, cut lead; packaging styles: bulk, taping
- Flame retardant epoxy resin coating ensures safety and durability
- RoHS compliant; designed for high frequency high voltage circuits
Buy the Buy Panasonic High Voltage Film Capacitor Part Number ECWH12123JV Online
Enhance your electronic designs with Panasonic high voltage film capacitors. Perfect for high-frequency and inverter applications, these capacitors feature excellent electrical characteristics, flame-retardant epoxy coating, and RoHS compliance. Easy to purchase online with various lead and packaging options, they deliver dependable performance at rated voltages up to 2000 VDC and capacitance from 0.0036 to 0.10 microfarads. Trust Panasonic's quality for durability and safety in your high-voltage circuit designs.
Buy Panasonic ECWH12123JV high voltage film capacitor now and ensure reliable performance in high-frequency inverter and resonance circuits.
Frequently Asked Questions
Where can I buy Panasonic ECWH12123JV?
You can click on the BUY or RFQ button to purchase ECWH12123JV from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part ECWH12123JV?
You can download the ECWH12123JV datasheet or visit the Panasonic website for support.
Who is the manufacturer of ECWH12123JV?
Panasonic
