Phoenix Contact 3047454 Datasheet & Stock

This is a test disconnect terminal block equipped with test socket screws for easy insertion of test plugs. It supports a nominal voltage of 500 V and a nominal current of 28 A. The connection method is screw terminal, accommodating two connections with wire cross sections ranging from 0.14 mm² to 6 mm² (AWG 26 to 10). The terminal block has a width of 6.2 mm, is blue in color, and is designed for mounting on NS 35/7.5 or NS 35/15 DIN rails.

View 3047454Datasheet [pdf]
