Phoenix Contact 3073995 Fuse Modular Terminal Block
The PHOENIX CONTACT UT 4-PE/HESI fuse modular terminal block provides a secure and organized solution for incorporating fuses into electrical systems. Designed for grounding applications, this terminal block accepts G fuses (5x20 mm) and is suitable for a wide range of industrial applications where overcurrent protection is critical. It features a compact design with a width of 6.2 mm and supports conductor cross-sections from 0.14 to 4 mm² (AWG 26-10). The terminal block's robust construction and reliable screw connection ensure long-lasting performance and safety.
Phoenix Contact 3073995 Fuse Modular Terminal Block Specifications:
- Number of levels: 1
- Number of connections: 2
- Nominal cross section: 4 mm²
- Color: black
- Insulating material: PA
- Flammability rating according to UL 94: V0
- Maximum power dissipation for nominal condition: 1.6 W
- Fuse: G / 5 x 20
- Fuse type: Glass / ceramics / ...
- Rated surge voltage: 6 kV
- Degree of pollution: 3
- Overvoltage category: III
- Insulating material group: I
- Maximum power dissipation: max. 1.6 W (With single arrangement of the fuse terminal block in the event of overload)
- Connection in acc. with standard: IEC 60947-7-2/IEC 60947-7-3
- Maximum load current: 6.3 A
- Nominal current IN: 6.3 A
- Nominal voltage UN: 500 V
- Conductor cross section solid min.: 0.14 mm²
- Conductor cross section solid max.: 6 mm²
- Conductor cross section flexible min.: 0.14 mm²
- Conductor cross section flexible max.: 6 mm²
- Conductor cross section AWG min.: 26
- Conductor cross section AWG max.: 10
- Connection method: Screw connection
- Stripping length: 9 mm
- Screw thread: M3
- Tightening torque, min: 0.6 Nm
- Tightening torque max: 0.8 Nm
- Packing unit: 1 STK
- GTIN: 4046356416238
- Weight per Piece (excluding packing): 25.600 g
- Custom tariff number: 85369095
- Country of origin: Poland
