Phoenix Contact FKCOR252ST508LR PCB connector
The Phoenix Contact FKCOR 2.5/2-ST-5.08-LR is a 2-pole female printed circuit board connector with a 5.08mm pitch. It features an automatic locking mechanism and an intuitive release lever in contrasting color for easy handling. The connector simplifies cabling with a conductor connection orthogonal to the direction of operation, suitable for DIN rail mounting. It supports quick, tool-free push-in connection with a spring contact and tin-plated conductors. The rated surge voltage is 4 kV (categories III/3, III/2, II/2), with rated voltages of 250V, 320V, and 630V respectively. It accommodates a nominal current of 12A with a nominal cross-section of 2.5mm², suitable for conductor cross sections from 0.2mm² to 2.5mm² (24–12 AWG). Designed for industrial applications, it can be combined with the MSTB 2.5 range connectors.
Phoenix Contact FKCOR252ST508LR PCB connector Specifications:
- Dimensions: Length 29.1mm, Width 19.16mm, Height 14.7mm
- Pitch: 5.08mm
- Rated voltage: 320V (III/2), 250V (Uy), 630V
- Rated surge voltage: 4kV
- Nominal current: 12A
- Nominal cross section: 2.5mm²
- Conductor cross section range: 0.2mm² – 2.5mm² (AWG 24–12)
- Connection method: Push-in spring connection
- Contact surface: Tin-plated
- Temperature range: Storage -40°C to 70°C, Operation -40°C to 100°C
- Material: Insulating material group according to standards
- Standards: EN-VDE, UL 94 VO flammability rating
- Number of positions: 2
Buy the Phoenix Contact FKCOR 2.5/2-ST-5.08-LR – Reliable PCB Connector for Industrial Applications
Purchase the Phoenix Contact FKCOR 2.5/2-ST-5.08-LR online for reliable, tool-free push-in connection in industrial environments. Its orthogonal conductor setup simplifies cabling, with quick locking and release mechanisms for efficient installation. Designed to handle up to 12A and rated at 320V, it features tin-plated contacts for longevity. Ideal for DIN rail mounting in control panels and industrial automation systems. This connector ensures secure electrical connections, providing flexibility with conductor strip ranges from 0.2mm² to 2.5mm², making it a versatile choice for technical professionals.
Get Phoenix Contact FKCOR 2.5/2-ST-5.08-LR today—built for ease of connection, precise performance, and durable industrial use.
Frequently Asked Questions
Where can I buy Phoenix Contact FKCOR252ST508LR?
You can click on the BUY or RFQ button to purchase FKCOR252ST508LR from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part FKCOR252ST508LR?
You can download the FKCOR252ST508LR datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of FKCOR252ST508LR?
Phoenix Contact
