Phoenix Contact 1703616 PCB Feed-Through Connector
This feed-through connector is rated for 76 A and 1000 V, designed for PCB mounting with a 2-position configuration and 10.16 mm pitch. It features screw connection with tension sleeves, providing secure, reliable contact. The connector has a green housing, a silver contact surface, and supports conductors with cross sections up to 16 mm². It offers high mechanical stability with a screwable flange and EMC shielding via an integrated shroud. Suitable for industrial applications, it complies with UL, cUL, and other safety standards, ensuring versatile use in power distribution and automation systems.
Phoenix Contact 1703616 PCB Feed-Through Connector Specifications:
- Nominal current: 76 A
- Rated voltage: 1000 V (category III/2)
- Number of positions: 2
- Pitch: 10.16 mm
- Connection method: Screw connection with tension sleeve
- Housing color: Green
- Contact surface: Silver
- Cross-sectional capacity: 16 mm²
- Solder pin diameter: 4.1 mm
- Mechanical stability: Screwable flange, snap-in locking or screws
- Standards: UL Recognized, cUL Recognized
- Approvals: UL, cUL, SEV, EAC
- Weight per piece: 31.2 g
Buy the Phoenix Contact 1703616 – Reliable PCB Feed-Through Connector for Industrial Applications
Get the Phoenix Contact PCB Feed-Through Connector now from our online store to ensure reliable, secure power distribution in your industrial systems. Designed with a 76 A current rating and 1000 V voltage capacity, this connector features a 2-position setup with a 10.16 mm pitch, screw terminal connections with tension sleeves, and a durable green housing with silver contact surfaces. Its EMC shielding and screwable flange provide enhanced stability. Perfect for automation, power distribution, and industrial control panels, order online for fast, convenient delivery and expert support.
Buy Phoenix Contact 1703616 now and experience unmatched reliability, secure connections, and robust industrial performance.
Frequently Asked Questions
Where can I buy Phoenix Contact 1703616?
You can click on the BUY or RFQ button to purchase 1703616 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part 1703616?
You can download the 1703616 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of 1703616?
Phoenix Contact
