Phoenix Contact FKCOR254STF508 PCB Connector
The FKCOR 2,5/4-STF-5,08 from Phoenix Contact is a 5.08 mm pitch, four-pole female printed circuit board connector featuring a screw flange for enhanced mechanical stability. Its conductor connection is oriented orthogonally to the device, simplifying cabling for DIN rail-mounted applications. The connector offers a quick, tool-free push-in connection with color-coded actuation levers for intuitive use. It includes an integrated test option for convenient testing and can be combined with the MSTB 2.5 range connector. Rated for 4 kV surge voltage and up to 630 V, it supports 12 A current and conductor sizes from 0.2 mm² to 2.5 mm², making it ideal for industrial automation and control systems.
Phoenix Contact FKCOR254STF508 PCB Connector Specifications:
- Number of positions: 4
- Connection method: Push-in spring connection
- Rated voltage: 320 V (III/2), 630 V (I/2)
- Rated surge voltage: 4 kV
- Rated current: 12 A
- Conductor cross section: 0.2 mm² to 2.5 mm² (24-12 AWG)
- Stripping length: 10 mm
- Dimensions: Length 23.7 mm, Width 30.3 mm, Height 14.3 mm
- Pitch: 5.08 mm
- Color: Green
- Contact surface: Tin plated
- Material: Female connector
- Environmental compliance: China RoHS, EFUP unlimited
Buy the Phoenix Contact FKCOR254STF508 – Reliable PCB Connector for Industrial Applications
Purchase the Phoenix Contact FKCOR 2,5/4-STF-5,08 online today and benefit from its quick push-in connection, screw flange for stability, and test options. Ideal for DIN rail-mounted devices, this connector supports up to 12 A, with a voltage rating of 630 V, and accommodates conductor sizes from 0.2 mm² to 2.5 mm² (24–12 AWG). Its 5.08 mm pitch ensures reliable and easy wiring in industrial automation, control panels, and electrical systems. Order now for efficient and secure connections that meet industry standards.
Get Phoenix Contact FKCOR254STF508 today—built for precision and long-lasting durability in industrial control systems.
Frequently Asked Questions
Where can I buy Phoenix Contact FKCOR254STF508?
You can click on the BUY or RFQ button to purchase FKCOR254STF508 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part FKCOR254STF508?
You can download the FKCOR254STF508 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of FKCOR254STF508?
Phoenix Contact
