Phoenix Contact FKCOR256ST508LR PCB connector

The Phoenix Contact FKCOR 2.5/6-ST-5.08-LR is a 6-pole female printed circuit board connector with a 5.08 mm pitch. It features an automatic locking mechanism and an intuitive release lever distinguished by contrasting colors for easy operation. The connector's conductor connection is orthogonal to the insertion direction, simplifying cabling of DIN-rail-mountable devices. It includes a quick, tool-free push-in connection with a spring-loaded, tin-plated contact for efficient wiring. The connector supports rated voltages up to 630V and surge voltages up to 4kV, with a rated current of 12A and a nominal cross section of 2.5 mm². Suitable for solid conductors from 0.2 mm² to 2.5 mm² (24AWG to 12AWG), it enables quick testing via an integrated test option and can be combined with MSTB 2.5 range connectors. Designed for industrial applications, it offers reliable, easy-to-use connections for DIN-rail-mounted devices.

View FKCOR256ST508LRDatasheet [pdf]

Buy the Buy Phoenix Contact PCB Connector Part Number FKCOR256ST508LR Online

Secure your electrical connections efficiently with the Phoenix Contact PCB connector. Featuring a push-in spring mechanism, 6 poles, and rated up to 630V, it's ideal for industrial wiring. Its orthogonal conductor connection simplifies cabling, while the automatic locking ensures secure contact. Compatible with solid and flexible conductors from 0.2 mm² to 2.5 mm² (AWG 24-12), it offers fast, tool-free installation. Perfect for DIN-rail-mountable devices, the connector combines ease of use with high reliability, making it a valuable component for your automation setup.

Buy Phoenix Contact FKCOR256ST508LR now and experience quick, reliable wiring with tool-free push-in connection and DIN-rail compatibility.
