Phoenix Contact 3044568 Grounding Terminal Block
This is a Phoenix Contact multi-conductor terminal block designed for grounding purposes. It features a 2.5 mm² wire cross-section capacity, a single-level design, and a screw connection mechanism. The terminal block is color-coded green and yellow for grounding identification.
Phoenix Contact 3044568 Grounding Terminal Block Specifications:
- Width: 5.2 mm
- Length: 65.4 mm
- Height: 46.9 mm
- Connection method: Screw connection
- Number of connections: 4
- Nominal cross section: 2.5 mm²
- Wire Range: 26 - 12 AWG
- Flammability rating according to UL 94: UL 94V-0
- Conductor cross section solid max.: 4 mm²
- Conductor cross section flexible max.: 2.5 mm²
- Tightening torque: 0.5 - 0.6 Nm
- Standards: UL Recognized, cUL Recognized, CSA, IEC 60947-7-2, DIN EN 45545-2 R22-R26
- Material: Steel, galvanized, passivated
- Color: Green-yellow
- Certification: UL, cUL, CSA, EAC, DNV GL, PRS
- Length in mm: 65.4
- Width in mm: 5.2
- Height in mm: 46.9
Buy the Phoenix Contact UT 2,5-QUATTRO-PE – Reliable Ground Terminal Block for Industrial Applications
Order the Phoenix Contact grounding terminal block UT 2,5-QUATTRO-PE online today to ensure reliable grounding solutions for industrial automation, railway, and process industries. Designed with a 2.5 mm² capacity, screw connection, and dual certification, this terminal block guarantees safety and durability. Its compact size, color-coded design, and certified standards make it ideal for efficient wiring and grounding tasks. Secure your connections with a trusted industry product and enjoy quick, hassle-free purchasing with fast delivery options available online.
Get Phoenix Contact UT 2,5-QUATTRO-PE today—built for precision and long-lasting durability in grounding and safety applications.
Frequently Asked Questions
Where can I buy Phoenix Contact 3044568?
You can click on the BUY or RFQ button to purchase 3044568 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part 3044568?
You can download the 3044568 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of 3044568?
Phoenix Contact
