Phoenix Contact FKCOR256STF508 PCB Connector
The FKCOR 2.5/6-STF-5.08 from Phoenix Contact is a 6-position female PCB connector with a 5.08mm pitch, featuring a screw flange for enhanced mechanical stability. The connector's conductors are connected orthogonally to the circuit board, simplifying wiring for DIN-rail-mounted devices. It offers a quick, tool-free push-in connection with color-coded actuation levers for easy handling. The device includes an integrated test option and can be combined with the MSTB 2.5 series connectors. Its rated surge voltage is 4kV (categories III/3, III/2, II/2). It supports rated voltages of 250V (III/3), 320V (III/2), and 630V (II/2), with a nominal current of 12A and a conductor cross-section range from 0.2mm² to 2.5mm² (24AWG to 12AWG). The contact is tin-plated, and the wire stripping length required is 10mm. Suitable for industrial applications.
Phoenix Contact FKCOR256STF508 PCB Connector Specifications:
- Number of positions: 6
- Pitch: 5.08 mm
- Rated surge voltage: 4kV
- Rated voltage: 250V (III/3), 320V (III/2), 630V (II/2)
- Rated current: 12A
- Conductor cross-section: 0.2mm² to 2.5mm² (24AWG to 12AWG)
- Connection method: Push-in spring connection
- Wire stripping length: 10mm
- Dimensions: Length 23.7mm, Width 40.46mm, Height 14.3mm
- Contact surface: Tin-plated
- Connection standard: EN-VDE
- Environmental compliance: China RoHS
- Made in Germany
- Compatibility: Can be combined with MSTB 2.5 range
Buy the Phoenix Contact Series FKCOR 2,5/6-STF-5.08: FKCOR256STF508
Purchase the Phoenix Contact FKCOR 2.5/6-STF-5.08 connector online today to ensure high-quality, reliable PCB connections for industrial applications. Featuring a 5.08mm pitch, six positions, push-in spring connection, and screw flange for enhanced mechanical stability, this connector simplifies wiring for DIN-rail-mounted devices. It supports rated voltages up to 630V and a current of 12A, with a conductor cross-section range from 0.2mm² to 2.5mm². The connector's contacts are tin-plated for durability and performance, and wire stripping requires just 10mm. An ideal choice for engineers seeking a resilient and easily installable PCB connection solution.
Get Phoenix Contact FKCOR256STF508 today—built for reliable PCB connections and industrial stability.
Frequently Asked Questions
Where can I buy Phoenix Contact FKCOR256STF508?
You can click on the BUY or RFQ button to purchase FKCOR256STF508 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part FKCOR256STF508?
You can download the FKCOR256STF508 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of FKCOR256STF508?
Phoenix Contact
