Phoenix Contact FKMCP1510ST381 PCB connector
The FK-MCP 1.5/10-ST-3.81 is a 10-position printed-circuit board connector featuring a push-in spring connection, rated for 8A and 160V, with a pitch of 3.81 mm. Made from durable PA insulators with a UL 94V-0 flammability rating, it ensures quick, tool-free wiring with defined contact force for long-term stability. Ideal for compact electronic assemblies, it offers reliable contact surface Tin and easy connection from one direction, fitting seamlessly into front device applications and enabling efficient testing.
Phoenix Contact FKMCP1510ST381 PCB connector Specifications:
- Type of contact: Female connector
- Number of positions: 10
- Connection method: Push-in spring connection
- Rated voltage: 160V (III/2), 320V (II/2)
- Rated surge voltage: 2.5 KV (III/3, III/2, II/2)
- Nominal current: 8A
- Rated cross section: 1.5mm²
- Maximum load current: 8A
- Insulating material: PA (Polyamide)
- Flammability rating: UL 94V-0
- Connection in accordance with EN-VDE standard
- Conductor cross-section: solid 0.14-1.5 mm², flexible 0.14-1.5 mm², with ferrule 0.25-1.5 mm²
- Wire AWG: 26-16
- Minimum AWG: 28, Maximum AWG: 16
- Mounting: Through-hole soldering or press-in technology
- Dimensions: Length 21mm, Height 12.4mm, Width 38.89mm, Pitch 3.81mm
Buy the Buy Phoenix Contact FK-MCP 1.5/10-ST-3.81 Part Number FKMCP1510ST381 Online
Purchase the Phoenix Contact FK-MCP 1.5/10-ST-3.81 online to streamline your electronic assembly processes. This 10-position PCB connector features a quick push-in spring connection, rated for 8A and 160V, with a pitch of 3.81 mm. Made from high-quality PA with UL 94V-0 flammability rating, it ensures long-term stable contacts with Tin surface plating. Its compact design enables seamless front device integration and effortless testing, making it an ideal choice for modern electronics manufacturing and maintenance.
Buy Phoenix Contact FK-MCP 1.5/10-ST-3.81 now and experience reliable, tool-free PCB connection suitable for compact electronic assemblies.
Frequently Asked Questions
Where can I buy Phoenix Contact FKMCP1510ST381?
You can click on the BUY or RFQ button to purchase FKMCP1510ST381 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part FKMCP1510ST381?
You can download the FKMCP1510ST381 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of FKMCP1510ST381?
Phoenix Contact
