Phoenix Contact FKMCP153ST35 PCB Connector
This PCB connector features a push-in spring connection method, rated for 8 A and 160 V, with 3 positions and a 3.5 mm pitch. It’s designed for reliable, tool-less installation, with stable contact force and color-coded actuation levers for easy use. Suitable for front device integration, it offers quick testing options and adheres to safety standards like UL 94 VO flammability rating. Crafted from durable PA insulation material with tin contact surfaces, it ensures long-term stability in industrial applications.
Phoenix Contact FKMCP153ST35 PCB Connector Specifications:
- Number of positions: 3
- Pitch: 3.5 mm
- Rated current: 8 A
- Rated voltage: 160 V
- Connection method: Push-in spring connection
- Insulating material: PA
- Flammability rating: UL 94 VO
- Conductor cross section (solid/flexible): 0.14-1.5 mm²
- Conductor cross section (AWG): 26-16
- Maximum load current: 8 A
- Mounting: Device front integration, compatible with THR soldering, wave, press-in, and through hole reflow technology
- Contact surface: Tin
- Dimensions: Length: 12 mm; Height: 23 mm; Width: 10 mm
- Temperature range: -55°C to +105°C
Buy the Phoenix Contact FK-MCP 1.5/3-ST-3.5 – Reliable PCB Connector for Industrial Applications
Enhance your industrial wiring with the Phoenix Contact PCB connector, designed for quick and secure push-in connections, offering stable contact force and tool-less installation. With a rated current of 8 A and a voltage of 160 V, it ensures reliable power distribution. Its compact design fits seamlessly into front device assemblies, and the UL 94 VO flammability rating guarantees safety. Made from durable PA material with tin contact surfaces, this connector provides long-term performance and easy testing options, ideal for complex automation systems.
Get Phoenix Contact FK-MCP 1.5/3-ST-3.5 today—built for precision and long-lasting durability in industrial environments.
Frequently Asked Questions
Where can I buy Phoenix Contact FKMCP153ST35?
You can click on the BUY or RFQ button to purchase FKMCP153ST35 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part FKMCP153ST35?
You can download the FKMCP153ST35 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of FKMCP153ST35?
Phoenix Contact
