Phoenix Contact MVSTBU252GFB508 Industrial Terminal Base Strip
This is a 2-position base strip component designed for screw connection with tension sleeve, rated for 12 A and 320 V, featuring a 5.08 mm pitch and tin contact surface. Ideal for device wiring and automation solutions, it can be directly mounted onto plates or housings, and is compatible with the MVSTB range. Made from durable PA insulator, it adheres to UL 94 vo flammability standards, with reliable screw threads M3, and a stripping length of 7 mm, ensuring secure and versatile connections in industrial environments.
Phoenix Contact MVSTBU252GFB508 Industrial Terminal Base Strip Specifications:
- Number of positions: 2
- Rating Voltage: 320 V (III/2)
- Rated current: 12 A
- Connection method: Screw connection with tension sleeve
- Contact surface: Tin
- Insulating Material: PA
- Flammability Rating: UL 94 V-0
- Screw Thread: M3
- Tightening torque: 0.5 to 0.6 Nm
- Conductor cross section: 0.2 mm² to 2.5 mm² (solid or flexible)
- Wire AWG: 24 to 12
- Pitch: 5.08 mm
- Width: 21.48 mm
- Stripping length: 7 mm
- Environmental Compliance: China RoHS
- Standards: EN-VDE, UL, cUL Recognized, CB Scheme, EAC, CSA
Buy the Phoenix Contact MVSTBU 2,5/ 2-GFB-5,08 – Reliable Industrial Connection Components
Purchase the Phoenix Contact MVSTBU 2,5/ 2-GFB-5,08 now online and equip your automation systems with high-quality, reliable connection components. Designed for ease of installation, it offers a secure screw connection with tension sleeve, rated for 12 A at 320 V, with a pitch of 5.08 mm. Made from durable PA material and compliant with UL and VDE standards, this base strip is ideal for versatile industrial wiring, ensuring safety and longevity in demanding environments. Shop now for fast delivery.
Order your Phoenix Contact MVSTBU 2,5/ 2-GFB-5,08 base strip today and ensure secure, durable connections for your industrial automation projects.
Frequently Asked Questions
Where can I buy Phoenix Contact MVSTBU252GFB508?
You can click on the BUY or RFQ button to purchase MVSTBU252GFB508 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part MVSTBU252GFB508?
You can download the MVSTBU252GFB508 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of MVSTBU252GFB508?
Phoenix Contact
