Phoenix Contact IC254G508 PCB connection strip
The IC 2.5/4-G-5.08 base strip is a durable, green-colored connection component designed for PCB and wave soldering applications. Rated at 12 A and 320 V, it features four positions with a 5.08 mm pitch, ensuring reliable and clear separation of inputs and outputs. Made from tin-contact surface material and PA insulation, the strip complies with UL 94 V-0 flammability standards and standard EN-VDE. Suitable for shock-proof applications, it supports wave soldering for secure mounting in various electrical and automation systems.
Phoenix Contact IC254G508 PCB connection strip Specifications:
- Rated Current: 12 A
- Rated Voltage: 320 V
- Number of Positions: 4
- Pitch: 5.08 mm
- Contact Surface: Tin
- Insulation Material: PA
- Flammability Rating: UL 94 V-0
- Dimensions: Height 13.7mm, Length of solder pin 3.5mm, Pin dimensions 0.48x1.14mm, Hole diameter 1.4mm
- Constructional height: 10.2mm
- Color: Green
- Mounting: Wave soldering, Press-in, or DIN rail
- Rated Surge Voltage: 4 kV
- Application: PCB, wave soldering, DIN rail mounting, shock-proof use
Buy the Buy Phoenix Contact IC 2.5/4-G-5.08 Part Number IC254G508 Online
Purchase the Phoenix Contact IC 2.5/4-G-5.08 base strip online today to ensure high-quality, reliable electrical connections in your projects. Designed with four positions and a 5.08 mm pitch, this green base strip is ideal for PCB and wave soldering applications, rated at 12 A and 320 V. Its durable tin contact surface and PA insulation meet industry standards, providing excellent safety and shock-proof capabilities. Trust Phoenix Contact to deliver precision-engineered components that enhance your electrical system performance.
Buy Phoenix Contact IC 2.5/4-G-5.08 now and experience unmatched reliability and performance in electrical connections and automation systems.
Frequently Asked Questions
Where can I buy Phoenix Contact IC254G508?
You can click on the BUY or RFQ button to purchase IC254G508 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part IC254G508?
You can download the IC254G508 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of IC254G508?
Phoenix Contact
