Phoenix Contact MCV153GF35LR Modular Connector Strip
The base strip MCV 1.5/3-GF-3.5-LR is a flexible connector component made from PBT insulation material, rated at 160V and 8A. It features three positions with a 3.5mm pitch, and is designed for wave soldering applications. With a length of 7.25mm and a hole diameter of 1.2mm, it complies with EN-VDE standards and UL 94 V-0 flammability. Suitable for industrial wiring, this green connector offers high reliability and ease of installation in control panels and electronic assemblies.
Phoenix Contact MCV153GF35LR Modular Connector Strip Specifications:
- Number of positions: 3
- Pitch: 3.5 mm
- Rated voltage: 160V (II/3 and III/2), 250V (Il/2)
- Nominal current: 8A
- Maximum load current: 8A
- Material: PBT
- Flammability rating: UL 94 V-0
- Color: Green
- Dimensions: Length 7.25mm, Hole diameter 1.2mm, Pin dimension 0.8 x 0.8mm
- Length of solder pin: 7mm
- Connection standard: EN-VDE
- Width: 34mm
- Additional: Made in Germany, Wave soldering compatible
Buy the Phoenix Contact Series Modular Connector: MCV153GF35LR
Order the Phoenix Contact MCV 1.5/3-GF-3.5-LR connector strip online today to ensure efficient, reliable, and safe wiring for your electronic or industrial control applications. This high-quality component features a 3.5mm pitch, rated at 160V and 8A, with a robust PBT insulator, making it ideal for wave soldering processes. Its compact design with three positions, precise dimensions, and compliance with industry standards guarantees optimal performance and easy installation, helping you complete your projects quickly and professionally.
Buy Phoenix Contact MCV 1.5/3-GF-3.5-LR now and experience high-quality, reliable electrical connections for industrial control systems.
Frequently Asked Questions
Where can I buy Phoenix Contact MCV153GF35LR?
You can click on the BUY or RFQ button to purchase MCV153GF35LR from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part MCV153GF35LR?
You can download the MCV153GF35LR datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of MCV153GF35LR?
Phoenix Contact
