Phoenix Contact PC63GL2762 PCB Header
The PCB 6/3-GL2-7,62 connector is a robust printed circuit board header rated for 41 A, featuring three positions and a 7.62 mm pitch. Designed for wave soldering, this black male connector ensures high safety with increased touch protection and a reliable tin contact surface. It's compatible with worldwide mounting standards and uses a proven plug-in power COMBICON system, making PCB replacements straightforward. Suitable for industrial automation and electronic projects requiring secure, high-current connections with easy handling and maximum safety features.
Phoenix Contact PC63GL2762 PCB Header Specifications:
- Number of positions: 3
- Pitch: 7.62 mm
- Contact surface: Tin
- Contact type: Male connector
- Color: Black (9005)
- Height: 13.5 mm
- Mounting: Wave soldering
- Nominal current: 41 A
- Nominal voltage: 300 V (for some variants), 600 V
- Approval: cULus Recognized
- Product family: PC 6/..-GL2
- Type of locking: 0°
- Conductor connection: Male plug-in system
- Packaging: Packed in cardboard
- Weight per piece: 9.2 g
- Country of origin: China
Buy the Phoenix Contact Series PC 6/..-GL2 PCB Header: PC63GL2762
Enhance your electronic assemblies with this high-quality PCB header designed for industrial and automation applications. Featuring three positions, a 7.62 mm pitch, and wave soldering compatibility, it offers excellent contact reliability and maximum safety through its tin contact surface and increased touch protection. Easy to replace thanks to its plug-in system, this black male connector is suitable for high currents up to 41 A and voltages up to 600 V, making it a versatile choice for demanding electronic projects.
Get Phoenix Contact PC 6/3-GL2-7,62 today—built for precision, safety, and reliable high-current connections in industrial electronics.
Frequently Asked Questions
Where can I buy Phoenix Contact PC63GL2762?
You can click on the BUY or RFQ button to purchase PC63GL2762 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part PC63GL2762?
You can download the PC63GL2762 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of PC63GL2762?
Phoenix Contact
