Phoenix Contact TDPT256SP508 PCB Terminal Block
The PCB terminal block TDPT 2,5/6-SP-5,08 is a versatile, wave solder-compatible connector with push-in spring connection, rated for 32 A at 400 V. Designed with a pitch of 5.08 mm and six positions, it ensures stable contact with long-term reliability due to defined contact force. Its green housing features linear double pinning and a solder pin length of 3.5 mm, accommodating solid or flexible conductors from 0.2 mm² to 4 mm². It complies with relevant standards and is suitable for various industrial wiring applications, offering ease of use and safety in electrical installations.
Phoenix Contact TDPT256SP508 PCB Terminal Block Specifications:
- Rated current: 32 A
- Rated voltage: 400 V
- Pitch: 5.08 mm
- Number of positions: 6
- Connection method: Push-in spring connection
- Mounting: Wave soldering
- Housing color: Green
- Pin spacing: 8.7 mm
- Length: 18 mm
- Width: 31.28 mm
- Height: 19 mm
- Solder pin: 3.5 mm
- Conductor cross section solid/flexible: 0.2 mm² to 4 mm²
- Conductor cross section AWG: 24 to 12
- Surface: Tin-plated Cu alloy
- Ambient temperature (operation): -40°C to 105°C
- Pull-out force: >10 N for 0.2 mm², >60 N for 4 mm²
- Standards: IEC 60947-7-4, UL 94V-0
- Weight per piece: 12.4 g
Buy the Buy Phoenix Contact PCB Terminal Block Part Number TDPT256SP508 Online
Purchase the Phoenix Contact PCB terminal block TDPT 2,5/6-SP-5,08 online for efficient, secure wiring in industrial control panels. Featuring push-in spring connection technology, this green housing terminal offers six positions at 5.08 mm pitch, rated for 32 A and 400 V. Its wave soldering capability ensures easy mounting for high-volume manufacturing. The terminal supports a range of conductor sizes from 0.2 mm² to 4 mm², providing a reliable connection. Order now to benefit from fast delivery, extensive technical support, and compatibility with standard industrial wiring practices.
Buy Phoenix Contact TDPT 2,5/6-SP-5,08 now and experience reliable industrial connections with quick push-in wiring and robust design.
Frequently Asked Questions
Where can I buy Phoenix Contact TDPT256SP508?
You can click on the BUY or RFQ button to purchase TDPT256SP508 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part TDPT256SP508?
You can download the TDPT256SP508 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of TDPT256SP508?
Phoenix Contact
