Phoenix Contact TDPT258SC508 PCB Terminal Block
The PCB terminal block TDPT 2,5/8-SC-5,08 by Phoenix Contact is designed for reliable electrical connections with a pitch of 5.08 mm and 8 positions. It features screw connection with tension sleeve, ideal for wave soldering mounting, and offers a rated current of 24 A and voltage of 400 V. The device has a green housing, tin-plated Cu alloy contacts, and is compliant with RoHS standards. Suitable for various wire cross sections, it ensures secure and maintainable connections in industrial electrical systems.
Phoenix Contact TDPT258SC508 PCB Terminal Block Specifications:
- Pitch: 5.08 mm
- Number of positions: 8
- Rated current: 24 A
- Rated voltage: 400 V
- Connection method: Screw connection with tension sleeve
- Mounting: Wave soldering
- Housing color: Green
- Material: Copper alloy, tin-plated
- Pin dimensions: 0.9 x 0.9 mm
- Dimensions: Length 18 mm, Width 41.44 mm, Height 19 mm
- Solder pin length: 3.5 mm
- Hole diameter: 1.4 mm
- Rated surge voltage: 4 kV
- Standards: EN-VDE, UL 94 VO flammability
- Conductor cross-section: 0.2 mm² to 4 mm² solid, 0.2 mm² to 2.5 mm² flexible
- RoHS compliant
- Packaging: 50 pieces per box
Buy the Buy Phoenix Contact PCB Terminal Block Part Number TDPT258SC508 Online
Order the Phoenix Contact PCB terminal block with 8 positions and a 5.08 mm pitch online today. This robust device features screw connection with tension sleeve, suitable for wave soldering, and offers rated current of 24 A at 400 V. Made from tin-plated copper alloy, it ensures reliable electrical contact with secure wire capacity from 0.2 mm² to 4 mm². Perfect for industrial wiring, automation projects, and maintenance, this product guarantees durability, ease of installation, and high performance in demanding environments.
Get Phoenix Contact TDPT 2,5/8-SC-5,08 today—designed for secure, reliable connections in industrial automation and wiring systems.
Frequently Asked Questions
Where can I buy Phoenix Contact TDPT258SC508?
You can click on the BUY or RFQ button to purchase TDPT258SC508 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part TDPT258SC508?
You can download the TDPT258SC508 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of TDPT258SC508?
Phoenix Contact
