ROHM RGTH60TK65DGC11 Power Semiconductor Module
The RGTH60TK65D is a 650V, 30A trench IGBT designed for efficient power switching in applications like power conditioners and UPS systems. It features low collector-emitter saturation voltage, high-speed switching, soft recovery diode built-in, and ROHS compliance, ensuring reliable operation with low power dissipation. The device offers a maximum collector-emitter voltage of 650V, a collector current of 17A at 100°C, and a power dissipation of 30W. Its thermal resistance values are 2.43°C/W (junction-case IGBT) and 3.76°C/W (junction-case diode).
ROHM RGTH60TK65DGC11 Power Semiconductor Module Specifications:
- Collector-Emitter Voltage: 650V
- Collector Current: 17A at 100°C, Pulsed: 120A
- Diode Forward Current: 16A, Pulsed: 120A
- Power Dissipation: 30W
- Operating Junction Temperature: -40°C to +175°C
- Storage Temperature: -55°C to +175°C
- Thermal Resistance (IGBT Junction - Case): 2.43°C/W
- Thermal Resistance (Diode Junction - Case): 3.76°C/W
- Gate-Emitter Voltage: +30V
- Collector-Emitter Breakdown Voltage: 650V
- Gate-Emitter Leakage Current: <200nA
- Switching Times: On delay 27-40ns, Off delay 105-120ns
Buy the Buy ROHM RGTH60TK65D Part Number RGTH60TK65D Online
Purchase the ROHM RGTH60TK65D high-voltage trench IGBT online today for reliable power switching solutions. Designed for efficient operation in power conditioners, UPS, and industrial systems, this device offers a maximum collector-emitter voltage of 650V, high pulsed current capacity, and built-in fast recovery diode. With low saturation voltage, high-speed switching, and ROHS compliance, it ensures optimal performance and safety. Easy to integrate, this module is the perfect choice for modern power conversion needs, providing durability and energy efficiency for demanding applications.
Order your ROHM RGTH60TK65D high-voltage trench IGBT today and ensure your power projects operate with high efficiency and reliability.
Frequently Asked Questions
Where can I buy ROHM RGTH60TK65DGC11?
You can click on the BUY or RFQ button to purchase RGTH60TK65DGC11 from an authorized ROHM distributor.
How do I troubleshoot issues or seek technical support for part RGTH60TK65DGC11?
You can download the RGTH60TK65DGC11 datasheet or visit the ROHM website for support.
Who is the manufacturer of RGTH60TK65DGC11?
ROHM
