SCS 770754 Mini Air Ionizer
The SCS Mini Air Ionizer is a compact, self-contained ionizing air blower engineered to effectively neutralize static charges from non-conductive objects. Utilizing proprietary circuitry, it generates balanced positive and negative ions, maintaining stability despite voltage and speed fluctuations. Meeting ANSI/ESD S20.20 standards, this ionizer is ideal for applications requiring precise static charge control in electronics manufacturing, cleanrooms, and packaging processes. It reduces static charge of ±1000V to ±100V in less than 4 seconds at a distance of 1 foot.
SCS 770754 Mini Air Ionizer Specifications:
- Input Voltage and AC Power Adapter Frequency (120VAC): Power Input: 120VAC, 60 Hz
- Power Output (120VAC): 24VAC, 500mA
- Input Voltage and AC Power Adapter Frequency (230VAC): Power Input: 230VAC, 50 Hz
- Power Output (230VAC): 24VAC, 500mA
- Power Consumption: 5 W
- Dimensions: 4.5" x 3.3" x 2.0" (including bracket) (114 mm x 84 mm x 51 mm)
- Weight: 0.75 lbs (0.3 kg)
- Balance (Offset Voltage): ±20V at 12"
- Neutralization Time: < 4 seconds (Discharge) at 12"
- Maximum Airflow: 24 CFM
- Certifications: cULus
- Origin: China
