SENSIRION SHT21P Humidity and Temperature Sensor
The SHT21P is a humidity and temperature sensor that integrates a capacitive humidity sensor, a bandgap temperature sensor, and specialized analog and digital circuitry on a single CMOSens® chip. This design offers high accuracy and stability with low power consumption. The sensor features a protective over-molding (excluding the humidity sensing area) for durability and long-term stability. It provides fully calibrated measurements, an analog output with PWM interface, and operates within a temperature range of -40°C to 125°C. The standard version has an accuracy of ±2% relative humidity and is suitable for both high-volume production and low-volume applications, including sensing and instrumentation, as well as signal processing.
SENSIRION SHT21P Humidity and Temperature Sensor Specifications:
- Sensor Type: CMOSens® chip integrating capacitive humidity sensor and bandgap temperature sensor
- Output Interface: Analog PWM, converted via low pass filter
- Accuracy: ±2% RH, ±0.3°C typ
- Resolution: 12-bit humidity, 14-bit temperature
- Operating Range: -40°C to 125°C, 0-100% RH
- Response Time: 5 to 30 seconds (Humidity), 8 seconds (Temperature)
- Supply Voltage: 2.1V to 3.6V, recommended 3.0V
- Supply Current: >180 pA
- Power Dissipation: >0.54 mW
- PWM Frequency: 108-132 Hz (typ 120Hz)
- Long term drift: <0.25% RH/year, <0.02°C/year
- Material: Silicon sensor chip, Cu leadframe, epoxy mold, RoHS and WEEE compliant
- Package: DFN 3x3mm die with bottom pad, reflow solderable
- Storage Conditions: 10°C - 50°C, 20-60% RH in sealed ESD packaging
- Certifications: RoHS, WEEE compliant, high ESD immunity
Buy the Buy Sensirion SHT21P Humidity Temperature Sensor Part Number SHT21P Online
Order the Sensirion SHT21P humidity and temperature sensor online today to secure reliable measurements with high accuracy, low power operation, and durable DFN packaging. Ideal for automation, instrumentation, and environmental monitoring, this fully calibrated sensor offers a linear analog PWM output, operates from -40°C to 125°C, and provides long-term stability. With quick response times and RoHS compliance, this sensor guarantees quality and performance for critical sensing needs in manufacturing, testing, and environmental control systems.
Buy Sensirion SHT21P now and experience unmatched reliability and performance with low power consumption and high stability for industrial sensing applications.
