STMICROELECTRONICS STTH8S06FP High-Voltage Rectifier Diode
The STTH8S06 is an ultrafast high-voltage rectifier diode designed using 600 V planar technology. It features a fast reverse recovery time of approximately 12 ns, low reverse recovery current, and low thermal resistance, making it ideal for high-frequency power switching, power supplies, and rectification applications. Its insulated package options include TO-220FPAC and DPAK, supporting operating currents up to 44A and surge currents up to 60A. This device ensures reduced switching losses, higher efficiency, and reliable performance in demanding power conversion systems.
STMICROELECTRONICS STTH8S06FP High-Voltage Rectifier Diode Specifications:
- Repetitive peak reverse voltage: 600 V
- Average forward current: 8 A
- Surge non-repetitive forward current: 60 A
- Maximum junction temperature: 175°C
- Typical forward voltage drop: 3.4 V at 8A
- Reverse recovery time: 12 ns
- Reverse recovery current: 16-22 A
- Thermal resistance junction to case: 5.5°C/W (TO-220FPAC)
- Package options: TO-220AC, TO-220FPAC, DPAK
- Insulating voltage: 2000 V (TO-220FPAC)
- Storage temperature: -65°C to +175°C
Buy the STMicroelectronics Series Ultrashort High Voltage: STTH8S06FP
Purchase the STTH8S06 ultrafast high-voltage rectifier diode online today. Featuring 600 V blocking voltage, 44A current capacity, and fast recovery time, it is ideal for demanding power switching, power supplies, and rectification applications. The device offers low conduction and switching losses, supported by insulated package options like TO-220FPAC and DPAK for easy mounting. Ensure your power systems operate efficiently and reliably with this durable, high-performance diode—available for quick delivery and easy online ordering.
Order your STMicroelectronics SeriesUltrafast High Voltage Rectifier today and ensure high efficiency and reliable switching in your power conversion projects.
Frequently Asked Questions
Where can I buy STMICROELECTRONICS STTH8S06FP?
You can click on the BUY or RFQ button to purchase STTH8S06FP from an authorized STMICROELECTRONICS distributor.
How do I troubleshoot issues or seek technical support for part STTH8S06FP?
You can download the STTH8S06FP datasheet or visit the STMICROELECTRONICS website for support.
Who is the manufacturer of STTH8S06FP?
STMICROELECTRONICS
