TDK Corporation VLS252010HBX2R2M1 Power inductor
The VLS252010HBX-1 is a magnetic shield type wound inductor designed for power circuits, utilizing metallic magnetic material for high current capacity and high-density mounting compatibility, suitable for compact power supply modules, smartphones, tablet terminals, HDDs, SSDs, and portable devices. Its high magnetic shield construction ensures minimal magnetic interference. Operating within a temperature range of -40°C to +105°C, it features precise inductance values, low resistance, and robust construction for reliable performance in various electronic applications, making it ideal for modern power management solutions requiring high efficiency and stability.
TDK Corporation VLS252010HBX2R2M1 Power inductor Specifications:
- Inductance: 2.5x2.0x1.0 mm size, operating temperature: -40°C to +105°C, storage temperature: -40°C to +105°C
- Core Material: Metallic magnetic, high magnetic shield, compatible with high-density mounting
- Reel Quantity: 2000 pieces, individual weight: 26 mg
- Maximum DC Resistance: 0.029 Ω at 0.24 µH, 0.031 Ω at 0.33 µH, 0.035 Ω at 0.47 µH, 0.048 Ω at 0.68 µH, 0.065 Ω at 1.0 µH, 0.094 Ω at 1.5 µH, 0.120 Ω at 2.2 µH, 0.178 Ω at 3.3 µH, 0.250 Ω at 4.7 µH, 0.406 Ω at 6.8 µH
- Rated Current: Up to approximately 6.55 A for 0.24 µH, 5.03 A for 0.33 µH, 4.53 A for 0.47 µH, 3.62 A for 0.68 µH, 3.22 A for 1.0 µH, 2.70 A for 1.5 µH, 2.30 A for 2.2 µH, 1.60 A for 3.3 µH, 1.40 A for 4.7 µH, 1.10 A for 6.8 µH
- Dimensions: 2.5mm x 2.0mm x 1.0mm, weight approximately 26 mg, packaging style: reel for automated pick-and-place
Buy the Buy TDK VLS252010HBX-1 Power Inductor Part Number VLS252010HBX-1 Online
Purchase the TDK VLS252010HBX-1 power inductor online today to ensure your electronic projects benefit from high magnetic shielding, excellent current handling, and temperature stability. This high-quality component is suitable for modern power circuits, smart devices, and portable electronics. Its compact size and robust design make it ideal for space-constrained applications, providing reliable performance and long-term durability. Order now to enhance your power management solutions with this trusted component, optimized for efficiency and stability in demanding environments.
Get TDK VLS252010HBX-1 power inductor today—built for high current and reliable performance in compact electronics.
Frequently Asked Questions
Where can I buy TDK Corporation VLS252010HBX2R2M1?
You can click on the BUY or RFQ button to purchase VLS252010HBX2R2M1 from an authorized TDK Corporation distributor.
How do I troubleshoot issues or seek technical support for part VLS252010HBX2R2M1?
You can download the VLS252010HBX2R2M1 datasheet or visit the TDK Corporation website for support.
Who is the manufacturer of VLS252010HBX2R2M1?
TDK Corporation
