TDK Corporation VLS5045EX220MH Automotive Power Inductor
The VLS5045EX-H series inductors are high-performance, wound ferrite components designed for automotive power circuits. They feature a magnetic shield construction, enabling high-density mounting and larger current capacity with lower Rdc. These inductors operate within a temperature range of -40 to +125 °C, ensuring reliability in demanding automotive environments. Suitable for electronic control units, airbags, headlights, and ABS systems, they comply with AEC-Q200 standards. These inductors offer excellent electrical characteristics, including rated currents up to 0.58 A, inductance values up to 220 μH, and comprehensive testing for durability and stability in automotive applications.
TDK Corporation VLS5045EX220MH Automotive Power Inductor Specifications:
- Dimensions: 5.35 x 5.65 x 4.5 mm
- Inductance Range: 1.0 μH to 220 μH
- Rated Current: up to 0.58 A
- Operating Temperature: -40 to +125 °C
- Temperature Range (Storage): -40 to +125 °C
- Material: Magnetic shield wound ferrite
- Compliance: AEC-Q200
- Frequency Measurement: Up to 10 MHz
- DC Resistance: 0.015 Ω to 0.73 Ω
- Soldering Profile: Reflow soldering at 220°C peak for 40s
- Package: Reel, 1500 pcs/reel
- Dimensions in mm for recommended land pattern: A=5.35, B=5.65, K=47
- Manufactured for automotive applications including ECM, airbags, headlights, and electronic power steering
Buy the AutoPower VLS5045EX-H – Reliable Automotive Inductors for Industrial Applications
Discover the high-quality VLS5045EX-H series inductors, engineered for automotive power systems. Featuring magnetic shielding, high current capacity, and a wide temperature range, these inductors meet strict automotive standards including AEC-Q200. Ideal for engine control modules, airbags, headlights, and ABS, their precision manufacturing guarantees durability and consistent performance. Order online now to benefit from fast shipping, competitive pricing, and the confidence of using components trusted in automotive electronics. Perfect for engineers aiming for reliable power solutions.
Order your AutoPower VLS5045EX-H inductors today and ensure robust performance for automotive power circuits with superior reliability and magnetic shielding.
Frequently Asked Questions
Where can I buy TDK Corporation VLS5045EX220MH?
You can click on the BUY or RFQ button to purchase VLS5045EX220MH from an authorized TDK Corporation distributor.
How do I troubleshoot issues or seek technical support for part VLS5045EX220MH?
You can download the VLS5045EX220MH datasheet or visit the TDK Corporation website for support.
Who is the manufacturer of VLS5045EX220MH?
TDK Corporation
