TDK-LAMBDA DDA500ND2PP1205001 Industrial Power Converter
The DDA Series DIN rail mount, non-isolated step-down converters provide high power density and efficiency up to 95%. Suitable for creating high current output voltages from a single AC-DC power supply at 12V, 24V, or 48V. They feature a wide input range of 9 to 53V, adjustable output from 3.3V to 24V, and are convection cooled for easy installation. These industrial-grade power modules are ideal for automation, control systems, and industrial applications requiring reliable and efficient voltage regulation with certifications like IEC/UL/EN 62368-1.
TDK-LAMBDA DDA500ND2PP1205001 Industrial Power Converter Specifications:
- Input Voltage range: 9 to 53V (Turn on at 10V or greater)
- Input Current: 20A to 40A
- Efficiency: up to 95%
- Output Voltage: 3.3V to 24V adjustable
- Output Power Levels: 250W, 325W, 500W
- Output Ripple & Noise: 50-60mV (pk-pk)
- Line Regulation: 20-25mV
- Load Regulation: 100-150mV
- Switching Frequency: 400kHz
- Operating Temperature: -40°C to 100°C
- Cooling: Convection or forced air
- Size: 36.5 x 123.4 x 115 mm
- Weight: 450g
- Certifications: IEC/UL/EN 62368-1, CE, RoHS
- MTBF: >5 million hours at 40°C
Buy the Buy TDK-Lambda DDA Series Part Number DDA500ND2PP1205001 Online
Get your TDK-Lambda DDA500ND2PP1205001 DIN rail power supply online today. Designed for industrial automation and control systems, this high-efficiency converter offers 500W power, wide input voltage 9-53V, and adjustable output from 3.3V to 24V. Its compact size, convection cooling, and robust certifications make it ideal for demanding industrial environments. Enjoy fast shipping, secure ordering, and excellent technical support to keep your projects running smoothly with dependable and efficient power conversion.
Order your TDK-Lambda DDA500ND2PP1205001 power converter today and ensure reliable high current output for your industrial automation projects.
Frequently Asked Questions
Where can I buy TDK-LAMBDA DDA500ND2PP1205001?
You can click on the BUY or RFQ button to purchase DDA500ND2PP1205001 from an authorized TDK-LAMBDA distributor.
How do I troubleshoot issues or seek technical support for part DDA500ND2PP1205001?
You can download the DDA500ND2PP1205001 datasheet or visit the TDK-LAMBDA website for support.
Who is the manufacturer of DDA500ND2PP1205001?
TDK-LAMBDA
