TDK-LAMBDA KAS414 Industrial Power Supply
The KAS Series consists of 2-4W PCB-mounted power supplies designed for industrial, broadcast, and communication applications. They feature wide AC-DC input voltage ranges from 90 to 305VAC or 120 to 430VDC, with low no-load power consumption under 0.3W. The supplies operate within a temperature range of -40°C to +80°C, are convection cooled, and certified for safety standards including UL, CSA, and IEC. Suitable for professional environments, these power supplies offer high efficiency, overcurrent protection, and a compact resin case for reliable integration.
TDK-LAMBDA KAS414 Industrial Power Supply Specifications:
- Input Voltage Range: 90-305VAC or 120-430VDC
- Inrush Current Limiting: 30/50A at 115/230VAC; 15/25A
- Input Current: 75/55mA at 115VAC; 110/70mA at 230VAC
- No Load Power Consumption: <0.3W
- Temperature Range: -40°C to +80°C (linear derating above 60°C)
- Hold-up Time: >15ms at 115/230VAC
- Leakage Current: <0.25mA at <240VAC
- Operating Temperature: -40°C to +80°C, derate linearly
- Safety Certifications: UL, CSA, IEC, EN62368-1, CE Mark
- Size: 28.5 x 25.8 x 17.0 mm; 37.0 x 27.5 x 17.5 mm
- Weight: 19.9g and 26g models
- Case Material: UL 94V-0 resin, PCB mountable
- Withstand Voltage: 3kVAC input to output
- Immunity: EN55024, external varistor rated at 350Vrms
Buy the Buy TDK Lambda Power Supply Part Number KAS414 Online
Secure your TDK Lambda power supply KAS414 today and enjoy swift online ordering. Designed for industrial environments, this compact PCB-mount unit offers wide input voltage, high efficiency, and safety certifications for reliable operation across various professional applications. Perfect for broadcast, communication, and automation systems, it ensures stable power delivery with low no-load consumption, overcurrent protection, and a robust resin case. Order now to enhance your system’s reliability and streamline your installation process with our quick, hassle-free online purchase.
Buy TDK Lambda KAS414 now and experience unmatched reliability and performance in industrial power solutions.
Frequently Asked Questions
Where can I buy TDK-LAMBDA KAS414?
You can click on the BUY or RFQ button to purchase KAS414 from an authorized TDK-LAMBDA distributor.
How do I troubleshoot issues or seek technical support for part KAS414?
You can download the KAS414 datasheet or visit the TDK-LAMBDA website for support.
Who is the manufacturer of KAS414?
TDK-LAMBDA
