TDK-LAMBDA DRB240243A1 Three-phase Power Supply
The DRB240-24 series of three-phase DIN-Rail power supplies deliver 240W output with a stable 24V DC voltage, suitable for industrial automation and control systems. These units feature a wide input range of 3x350 to 3x575Vac, high efficiency exceeding 93%, low noise, and robust protections including overvoltage, overcurrent, and temperature safeguards. They support parallel and series configurations, with optional boost power up to 288W for handling capacitive loads. Compact and durable, these power supplies are compliant with IEC 61010 and UL/CSA standards, ensuring safe and reliable operation in demanding environments.
TDK-LAMBDA DRB240243A1 Three-phase Power Supply Specifications:
- Output Power: 240W
- Output Voltage: 24V DC
- Output Current: Nominal 10A, Boost up to 12A/2s
- Input Voltage Range: 3x350 to 3x575Vac
- Frequency Range: 47..63Hz
- Efficiency: Max. 93.2%
- Inrush Current: Max. 42A
- Protection: Overvoltage max. 32Vac, Overcurrent 150%, Overtemperature auto-recovery at 80°C
- Isolation: Input/Output 3.510Vac, Input/PE 2.210Vac
- Mounting: DIN-Rail (IEC 60715 compliant), width 55mm, height 129mm
- Dimensions: Width 55mm, Height 129mm, Depth 135.7mm (-A0) model, 138.2mm (-A1) model
- Weight: 780g
- Efficiency: Max. 93.2%, Typical Power Consumption: Max. 18W
- Operating Temperature: -25°C to +55°C, derating above 55°C
- Certifications: IEC 61010-1, UL, CSA, RoHS, WEEE
Buy the Buy TDK-Lambda DRB240-24-3-A1 Power Supply Part Number DRB240-24-3-A1 Online
Purchase the TDK-Lambda DRB240-24-3-A1 DIN-Rail power supply online today. With 240W output, 24V DC voltage, high efficiency exceeding 93%, and comprehensive protections, it is ideal for demanding industrial environments. Its compact size, broad input voltage range of 3x350 to 3x575Vac, and flexible configuration options including parallel and series operation make it versatile for various automation and control systems. Enjoy fast delivery and expert support when you buy directly from authorized distributors or the manufacturer's website.
Order your TDK-Lambda DRB240-24-3-A1 three-phase power supply today and ensure reliable industrial automation performance with high efficiency and robust protections.
Frequently Asked Questions
Where can I buy TDK-LAMBDA DRB240243A1?
You can click on the BUY or RFQ button to purchase DRB240243A1 from an authorized TDK-LAMBDA distributor.
How do I troubleshoot issues or seek technical support for part DRB240243A1?
You can download the DRB240243A1 datasheet or visit the TDK-LAMBDA website for support.
Who is the manufacturer of DRB240243A1?
TDK-LAMBDA
