TDK-LAMBDA DTM65PW150D Medical Power Supply
The DTM65PW150D is a high-efficiency medical-grade AC-DC power supply designed for medical and industrial applications. This 65W unit complies with DOE Level VI and EU Tier 2 standards, offering reliable performance with low off-load power consumption of less than 0.15W. It features an output voltage of 15V with a maximum current of 4A, wide input voltage range of 90-264VAC, and robust safety and EMC certifications. Its compact, lightweight design includes overcurrent, overvoltage, and overtemperature protection, ensuring safety and durability in demanding environments.
TDK-LAMBDA DTM65PW150D Medical Power Supply Specifications:
- Input Voltage Range: 90 - 264VAC (47 - 63Hz)
- Efficiency: >89%
- Power Output: 65W
- Output Voltage: 15V
- Output Current: 4A
- Inrush Current: <50A at 115VAC, <90A at 230VAC
- Offload Power Consumption: <0.15W
- Touch Current: <100pA
- Dimensions: 69 x 132 x 40mm
- Weight: 390g
- Safety Certifications: UL, EN/IEC60601-1, CSA
- Temperature Range: -20°C to +85°C
- Humidity: 10-90% RH
- Protection Features: OVP, OCP, OTP, short circuit
- Cable Length: 1050mm
- Cooling: Convection
- Withstand Voltage: Input to Ground 1.5kVAC, Input to Output 4kVAC
- Vibration (non-operating): 23.52m/s² (10-55Hz)
- Shock: <196.1 m/s² (20G)
- Size: 2.72 x 5.2 x 1.57 inches
- Connector: IEC 320-C14, Kycon KPP-4P
Buy the TDK-Lambda Series DTM65-D Medical Power Supply: DTM65PW150D
Secure your medical and industrial projects with the reliable TDK-Lambda DTM65PW150D power supply. This efficient 65W unit offers low power consumption, robust safety features, and a compact design suitable for various demanding environments. With comprehensive protection measures, wide input voltage range, and compliance with international standards, it ensures safety, durability, and consistent performance. Purchase online today and benefit from fast delivery, excellent support, and a trusted solution for critical applications.
Buy TDK-Lambda DTM65PW150D now and experience unmatched reliability and performance in medical-grade power applications.
Frequently Asked Questions
Where can I buy TDK-LAMBDA DTM65PW150D?
You can click on the BUY or RFQ button to purchase DTM65PW150D from an authorized TDK-LAMBDA distributor.
How do I troubleshoot issues or seek technical support for part DTM65PW150D?
You can download the DTM65PW150D datasheet or visit the TDK-LAMBDA website for support.
Who is the manufacturer of DTM65PW150D?
TDK-LAMBDA
