TDK-LAMBDA PXCM0348WD12 Medical Power Module
The PXC-M series offers medical-grade DC-DC converters with a wide 4:1 input range supporting dual 12/24V or 24/48V systems. Compact in size, measuring 1.25 x 0.8 inches, they feature high input-output isolation at 5kV, low input current of 2μA touch current, and minimal off-load power consumption, making them ideal for portable medical applications. Certified to IEC60601-1 and ES60601-1 standards, these modules support both single and dual outputs, ensuring reliable performance with efficiencies up to 89%. Suitable for demanding medical environments, they withstand surge voltages and electromagnetic interference while providing robust safety and operational features.
TDK-LAMBDA PXCM0348WD12 Medical Power Module Specifications:
- Input Voltage Range: 9-36V or 18-75V depending on model
- Output Voltage: 3.3V, 5V, 12V, 15V, 24V (single and dual outputs available)
- Maximum Output Power: 1050W to 3000W depending on model
- Efficiency: Up to 89%
- Isolation Voltage: 5kV input-output isolation
- Touch Current: 2μA maximum
- No Load Power Consumption: Less than specified by model
- Operating Temperature: 40°C to +105°C, with derating above 88°C
- Dimensions: 1.25 x 0.8 inches (31.8 x 20.3mm), Height 10.2mm
- Certifications: IEC60601-1, ES60601-1, CE, RoHS
- Surge Voltage: 50V for -24W models, 100V for -48W models
- Start-up Time: Max 30ms
- Ripple & Noise: 30–50mV depending on output
- Weight: About 14g, typical
Buy the Buy TDK-Lambda PXC-M Series Part Number PXCM0348WD12 Online
Enhance your medical device project with the compact and certified TDK-Lambda PXC-M series power modules. Designed for portable and fixed medical applications, these converters support wide input ranges, high isolation at 5kV, and low power consumption for longer battery life. With efficiencies up to 89%, they ensure stable performance under demanding conditions. Easy to integrate, these modules meet strict medical safety standards including IEC60601-1. Purchase online today to guarantee reliable, medical-grade power solutions for your critical applications and improve device performance with premium quality DC-DC converters.
Get TDK-Lambda PXC-M Series PXCM0348WD12 today—built for medical-grade reliability and portable power applications.
Frequently Asked Questions
Where can I buy TDK-LAMBDA PXCM0348WD12?
You can click on the BUY or RFQ button to purchase PXCM0348WD12 from an authorized TDK-LAMBDA distributor.
How do I troubleshoot issues or seek technical support for part PXCM0348WD12?
You can download the PXCM0348WD12 datasheet or visit the TDK-LAMBDA website for support.
Who is the manufacturer of PXCM0348WD12?
TDK-LAMBDA
