TE CONNECTIVITY 19031162 High Current Power Connector
This high-reliability, RoHS-compliant series of high-current connectors is designed for industrial applications, offering various configurations including panel, free hanging, and PCB mounting types. The connectors feature a unique crown band contact that ensures stable electrical performance up to 65A per contact, with options for gold or tin plating. Suitable for power distribution, automation, and semiconductor manufacturing, they are equipped with safety locks, IP protection, and modular housing for easy installation and maintenance in harsh environments. The series supports multiple positions and contact sizes, providing flexible, safe, and efficient connections for heavy-duty industrial equipment.
TE CONNECTIVITY 19031162 High Current Power Connector Specifications:
- Current Rating: up to 65A per contact
- Voltage Rating: 600V AC/DC
- Contact Material: Copper Alloy, Gold or Tin Plated
- Housing Material: UL94V-0 Glass-Reinforced Thermoplastic PBT
- Number of Positions: 4P (industry standard), with various configurations for power and signal lines
- Contact Resistance: 10mΩ max
- Dielectric Withstanding Voltage: 3000VAC
- Operating Temperature: -55°C to +105°C
- IP Protection: IP20 (finger protection), IP65/IP67 optional depending on model
- Crimp Tool Compatibility: Standard and specialized crimping tools available for wire size AWG 6-30
- Mechanical Durability: Up to 50 mating cycles
- Housing Features: Lock mechanism with safety and mis-insertion prevention, modular structure for easy assembly and maintenance
- Applicable Tools: Crimping tools, extraction tools, and safety caps; RoHS compliant and suitable for automation, power distribution, and industrial machinery.
Buy the TE Connectivity High Current Connector – Reliable Power for Industrial Applications
Purchase the TE Connectivity High Current Power Connector online now to ensure your industrial machinery is equipped with reliable, RoHS-compliant power solutions. With high current capacity up to 65A per contact, modular housing for easy installation, and safety features like locks and IP protection, this connector guarantees performance and safety. Whether for automation, manufacturing, or power distribution, order now and benefit from fast, secure online shopping, extensive technical support, and product availability for your high-demand industrial applications.
Order your TE Connectivity High Current Power Connector today and give your industrial projects the dependable power and safety they need.
Frequently Asked Questions
Where can I buy TE CONNECTIVITY 19031162?
You can click on the BUY or RFQ button to purchase 19031162 from an authorized TE CONNECTIVITY distributor.
How do I troubleshoot issues or seek technical support for part 19031162?
You can download the 19031162 datasheet or visit the TE CONNECTIVITY website for support.
Who is the manufacturer of 19031162?
TE CONNECTIVITY
