TE CONNECTIVITY 20582991 Board-to-Board Connector
The hermaphroditic blade and receptacle connector is a high-temperature resistant SMT component designed for in-line board-to-board applications. It features durable tin-plated brass contacts and UL 94V-0 housing for reliable electrical connections, supporting operating currents of 6 amps at 125VAC/125VDC and withstanding temperatures from -40°C to +105°C. Suitable for LED lighting controls, strips, and channel lettering, the connector ensures up to 10 mating cycles, offering a secure and resilient connection solution for industrial lighting and electronic applications.
TE CONNECTIVITY 20582991 Board-to-Board Connector Specifications:
- Operating Current: 6 AMPS
- Operating Voltage: 125VAC/125VDC
- Dielectric Withstanding Voltage: ISOOVAC
- Operating Temperature: -40°C to +105°C
- Mating Cycles: 10
- Housing Material: UL 94 V-0 thermoplastic
- Contacts: Copper Alloy, tin over nickel plated
- Dust Cover Material: PBT
- Physical Dimensions: Standard pitch 4.00 mm, maximum misalignment 0.13 mm
- Part Numbers available in Natural and Black colors, with multiple positions (2, 4, 6).
Buy the TE Connectivity 20582991 – Reliable Board-to-Board Connectors for Industrial Applications
Upgrade your electronic connection solutions with this high-temperature, reliable hermaphroditic board-to-board connector. Designed for in-line applications, it features UL 94V-0 housing and copper alloy contacts with tin plating, supporting 6A at 125VAC/125VDC. With a temperature range of -40°C to +105°C and up to 10 mating cycles, this connector ensures secure and durable performance for LED lighting controls, channel lettering, and other industrial lighting systems. Easy to install and highly dependable, it is available in multiple colors and configurations for versatile use.
Buy TE Connectivity 20582991 now and experience unmatched reliability and performance for your LED lighting and electronics projects.
Frequently Asked Questions
Where can I buy TE CONNECTIVITY 20582991?
You can click on the BUY or RFQ button to purchase 20582991 from an authorized TE CONNECTIVITY distributor.
How do I troubleshoot issues or seek technical support for part 20582991?
You can download the 20582991 datasheet or visit the TE CONNECTIVITY website for support.
Who is the manufacturer of 20582991?
TE CONNECTIVITY
