TE CONNECTIVITY 219040585 Mini K HV Precharge Relay
The TE Connectivity Mini K HV Precharge Relay is a compact and robust solution for high voltage precharge applications in hybrid, full battery electric vehicles, and fuel-cell cars. It's suitable for voltage levels up to 450VDC, with precharge and limiting break currents up to 20A. Available with PCB and plug-in terminals, this relay offers versatility in design and integration. Its robust construction and adherence to industry standards like IEC 61810-1 ensure reliable performance and longevity in automotive applications. Proper PCB layout and adherence to clearance and creepage distance requirements are crucial for safe and effective operation.
TE CONNECTIVITY 219040585 Mini K HV Precharge Relay Specifications:
- suitable_voltage_levels: up to 450VDC
- precharge_currents: up to 20A
- limiting_break_currents: up to 20A
- contact_arrangement: 1 form X (NO DM)
- rated_voltage: 400VDC
- max_switching_voltage_power: 450VDC / 9kW
- limiting_switching_current: 20A on/0A off: min. 105ops
- initial_contact_voltage_drop: typ. 150mV, max. 300 mV
- operate_time: typ. 2.5ms
- release_time: typ. 1ms
- mechanical_endurance: >106ops
- initial_dielectric_strength_open_contacts: 2800 VDC/1mA
- initial_dielectric_strength_contact_coil: 2800 VDC/1mA
- insulation_resistance_fault_break_ops: >200MΩ
- max_altitude: 4000m
- clearance_creepage: acc. IEC60664-1 (2007) for over voltage category I, pollution degree 2
- nominal_voltage: 12V
- min_max_energization_duration: max. 2s
- max_coil_temperature: 155°C
- coil_resistance: 50 Ω±10%
- coil_power: 2.9 W
- rated_coil_voltage: 12VDC
- eu_rohs_elv_compliance: compliant
- flammability_plastic_material: acc. UL94-HB
- ambient_temperature_range: -40°C to +85°C
- climatic_cycling: EN ISO 6988, 6 cycles, storage 8/16h
- temperature_cycling_shock: IEC 60068-2-14, Na, 10 cycles,-40/+85°C (5°C per min)
- damp_heat_constant: IEC 60068-2-3, Ca, 56 days, upper air temperature 40°C
- degree_of_protection_pcb_version: IEC 61810, RT III–immersion cleanable
- corrosive_gas: IEC 60068-2-42, 10 days
- wide_band_noise: IEC 60068-2-64, 10 to 1000Hz, 30.8 m/s2
- shock_resistance_functional: IEC 60068-2-27 (half sine), 11ms, 20g
- terminal_type: PCB and plug-in/QC
- pcb_version_weight: approx. 17g (0.6oz)
- plug_in_version_weight: approx. 39g (1.4oz)
- solderability_pcb_version: IEC 60068-2-20, Ta, method 1, hot dip 5s, 215°C
- resistance_to_soldering_heat_pcb_version: IEC 60068-2-20, Tb, method 1A, hot dip 10s, 260°C with thermal screen
