TE CONNECTIVITY 23678201 Wire-to-Wire Connector
The Dynamic 1000 SL series wire-to-wire connector is designed for narrow spaces in small industrial equipment and machinery, offering 80% smaller size than the D1200 series. Made with UL 94V-0 thermoplastic, it features reliable locking, keying, and easy mating, crimping for rapid installation. Suitable for robotics, AGVs, and servo motors, it handles wire sizes from AWG 22 to 30, operates at -55°C to 125°C, with a current of 4.5A per position, and withstands 1,500V AC for 1 minute, ensuring robust electrical and mechanical performance.
TE CONNECTIVITY 23678201 Wire-to-Wire Connector Specifications:
- Materials: Thermo plastic UL 94V-0 for housing, Copper alloy contact
- Operating Temperature: -55°C to 125°C
- Current Rating: 4.5A per position
- Voltage Rating: AC/DC 250V max
- Dielectric Withstand Voltage: AC 1,500V for 1 minute
- Wire Size Compatibility: AWG #22 to #30
- Locking and keying features enhance reliability
- Size: Smaller design suitable for tight spaces
- Application: Robotics, AGV, Servo motor
- Mating cycles: Approximately 30 times
Buy the TE Connectivity Series D1000 Slim Wire-to-Wire Connector: 23678201
Enhance your industrial and robotic applications with the TE Connectivity D1000 Slim Wire-to-Wire Connector, featuring compact design, high current capacity, and reliable locking. Suitable for narrow spaces, it offers easy-mating and crimping, with an operating temperature range of -55°C to 125°C. Designed for AWG 22 to 30 wire sizes, this connector supports up to 4.5A per position and withstands voltage up to 250V AC, making it ideal for robotics, AGVs, and automation systems. Purchase online today for quick, secure installation and optimal performance.
Order your TE Connectivity Series D1000 Slim Wire-to-Wire Connector today and ensure dependable electrical connections in tight industrial spaces.
Frequently Asked Questions
Where can I buy TE CONNECTIVITY 23678201?
You can click on the BUY or RFQ button to purchase 23678201 from an authorized TE CONNECTIVITY distributor.
How do I troubleshoot issues or seek technical support for part 23678201?
You can download the 23678201 datasheet or visit the TE CONNECTIVITY website for support.
Who is the manufacturer of 23678201?
TE CONNECTIVITY
