TE CONNECTIVITY 787805520M modular connector system
The Deutsch DMC-MD series offers reliable and modular fiber optic and electrical connectors designed for aerospace, defense, and marine applications. These connectors are lightweight, feature a durable composite shell with nickel plating, and support high-performance environmental qualifications such as temperature range from -55°C to +175°C, vibration, salt spray, and interfacial sealing. With compatibility for Ethernet modules, hybrid, fiber optic, and high-density contacts, they ensure secure, EMI-shielded connections. The system supports customization with various backshells, modules, and panel mounting options, making it ideal for cabin systems and aircraft network applications.
TE CONNECTIVITY 787805520M modular connector system Specifications:
- Housing: Composite, nickel plated
- Modules: Thermoplastic and fluoronated silicone
- Crimp Contacts: Copper alloy, plated gold over nickel
- PCB Contacts: Copper alloy, plated gold over nickel, with lead or ROHS.tinning option
- Temperature Range: -55°C to +175°C
- Vibration: 20 g
- Durability: 500 mating cycles
- Salt Spray: 500 hours
- Insulation Resistance: 5000 MO
- Contact Current Rating: Size 24: 3 A, Size 22: 5 A, Size 20: 7.5 A, Size 16: 13 A, Size 12: 23 A, Size 8: 46 A
- EMI Attenuation: 50 dB at 100 MHz, decreasing to 30 dB at 1000 MHz
- Physical Dimensions vary per module, with panel mounting cutouts designed for standard aerospace panels, supporting quick installation and secure connection.
Buy the Buy DEUTSCH DMC-MD Series Connectors Part Number 787805520M Online
Order the DEUTSCH DMC-MD connector system 787805520M online for aerospace, military, and marine applications. These lightweight, robust connectors are engineered for maximum reliability, supporting environmental standards from -55°C to +175°C, with excellent EMI shielding and durability. Designed with advanced composite shells and high-quality contacts, they facilitate quick, secure connections with various modules and backshell options. Perfect for cabin systems, aircraft, and defense projects, this system ensures high performance, easy installation, and long-lasting operation, making it an essential choice for mission-critical connectivity needs.
Get DEUTSCH DMC-MD 787805520M today—designed for high-reliability aerospace, defense, and marine fiber optic and electrical connections.
Frequently Asked Questions
Where can I buy TE CONNECTIVITY 787805520M?
You can click on the BUY or RFQ button to purchase 787805520M from an authorized TE CONNECTIVITY distributor.
How do I troubleshoot issues or seek technical support for part 787805520M?
You can download the 787805520M datasheet or visit the TE CONNECTIVITY website for support.
Who is the manufacturer of 787805520M?
TE CONNECTIVITY
