TE CONNECTIVITY SPD253 String Potentiometer
The SPD series is a compact, high-performance string potentiometer designed for precise linear measurement in limited spaces. It features a rugged polycarbonate IP67 enclosure suitable for indoor and outdoor environments, with dual output options of 4-20mA and 0-10Vdc. The sensor provides an adjustable measuring cable, easy installation, and mounting flexibility, making it ideal for OEM applications and single-piece use. Available with stroke ranges up to 50 inches, it ensures reliable, repeatable measurements, and comes with mounting brackets for quick setup.
TE CONNECTIVITY SPD253 String Potentiometer Specifications:
- Full Stroke Range: 0-4.75 to 0-50 inches
- Output Signal: 4...20 mA (2-wire) / 0...10 Vdc (user selectable)
- Input Voltage for 4...20 mA: 8-40 VDC
- Input Voltage for 0...10 Vdc: 12-32 VDC
- Accuracy: see ordering info
- Repeatability: 0.05% FS
- Resolution: essentially infinite
- Measuring Cable: 0.019-inch diameter nylon-coated stainless steel
- Sensor Type: Plastic-hybrid precision potentiometer
- Electrical Connection: M12 connector with mating plug included
- Enclosure: Glass-filled polycarbonate, IP67 rated
- Operating Temperature Range: -40°F to 160°F (-40°C to 70°C)
- Weight: approximately 4 lbs (1.81 kg) including sensor, bracket, and connector
Buy the TE Series SPD String Potentiometer: SPD253
Order the TE Series SPD253 string potentiometer online today and enjoy simple installation, durable IP67-rated enclosure, and versatile dual output options. Whether for OEM or single-piece applications, this compact sensor provides accurate, repeatable measurements up to 50 inches stroke. Its rugged design ensures reliable performance in harsh environments, and mounting brackets make setup effortless. Get your reliable linear position sensor now and optimize your industrial processes with ease and confidence.
Buy TE Series SPD253 string potentiometer now and experience unmatched flexibility, rugged IP67 housing, and dual output for precise industrial measurement.
