TE CONNECTIVITY T92P11D2224 High Power PCB Relay
The T92P11D22-24 is a high-power, general-purpose PCB relay with a DC coil and a 2-pole, 2form-C contact configuration featuring silver cadmium oxide contacts. Housed in a dust-protected plastic case with panel mounting via flanged cover and quick-connect terminals measuring 0.250 inches by 0.032 inches, it controls compressor loads up to 3.5 tons (110 LRA / 25.3 FLA). It complies with UL 508, UL 873, and VDE standards, offering 8mm air and 9.5mm surface spacing, UL Class F construction, and UL approval for 600VAC switching (1.5HP). Its dielectric coil-to-contact voltage is 4kV, making it suitable for industrial automation, HVAC, power management, and process control applications.
TE CONNECTIVITY T92P11D2224 High Power PCB Relay Specifications:
- Contact arrangement: 2 form C (2CO)
- Coil Voltage: 24VDC
- Contact Material: Silver cadmium oxide (AgCdO2)
- Maximum switching voltage: 600VAC
- Switching capacity: 1.5HP, 600VAC
- Contact ratings: 30A NO, 3A NC
- Dielectric strength: 4kV coil-to-contact
- Ambient temperature: -55°C to 85°C
- Case material: Dust protected plastic
- Mounting: Panel mount via flanged cover with quick connect terminals 0.250" x 0.032"
- Dimensions: Length 2.70 inches, Width 1.36 inches, Height 1.21 inches
- Insulation resistance: 4x10^9 Ohms
- Vibration resistance: 7.65mm max excursions, 10-55Hz
- Shock resistance: 400g
- Weight: 86g
- Compliance: UL, VDE, IEC 61810
Buy the Potter & Brumfield Series T92 High Power PCB Relay: T92P11D2224
Purchase the Potter & Brumfield Series T92P11D2224 high-power PCB relay online today and improve your automation projects with a durable, UL and VDE compliant switch rated at 600VAC. Designed for controlling compressor loads up to 3.5 tons, this relay features a 2-pole, 2form-C contact configuration with AgCdO contacts and a 24VDC coil. Its dust-protected plastic case and quick-connect terminals enable easy installation. Perfect for HVAC, industrial controls, and power distribution, ensuring operational reliability and safety.
Order your Potter & Brumfield Series T92P11D2224 high-power PCB relay today and enhance your industrial automation and HVAC control systems with reliable performance.
