TRACO POWER TBL090112 Industrial Power Supply
The TBL series provides compact, low-profile industrial power supplies suitable for building automation and factory applications. Designed with safety in mind, these UL 508 listed modules operate across an ambient temperature of -25°C to +70°C without additional cooling. They feature universal input, adjustable output voltage, short circuit and overload protection, and easy DIN-rail mounting. With power ratings from 15 to 150 W, they ensure reliable, worldwide compliance for commercial and residential automation systems, making them ideal for space-constrained panel installations.
TRACO POWER TBL090112 Industrial Power Supply Specifications:
- Input Voltage Range: 85 - 264 VAC, 47 - 63 Hz; 120 - 373 VDC (for selected models)
- Output Power: 15 W to 150 W
- Output Voltage: 5 VDC, 12 VDC, 24 VDC with adjustable range
- Output Current: 24A (5 V), 1.25A (12 V), 6.25A (24 V), up to 24A for 12 V models
- Efficiency: Up to 87%
- Operating Temperature: -25°C to +70°C
- Ripple and Noise: <100 mV pk-pk
- Protection: Short circuit, overload, overvoltage, electronic current limiting
- Safety Standards: UL 508, UL 1310, IEC/EN 60950-1, EN 61000-6-3, -6-2
- Mounting: DIN-rail or wall with bracket
- Dimensions: Vary by model, width from 26.3 mm to 175 mm
- Enclosure Material: UL 94V-0 rated plastic
- Certifications: UL, CB, CSA, Reach, RoHS
Buy the Buy Traco Power TBL Series Power Supply Part Number TBL090112 Online
Purchase the Traco Power TBL090112 power supply online now to ensure a dependable, space-saving solution for your automation and industrial power needs. This compact, UL-listed device features adjustable output voltage, high efficiency, and robust protection features, making it ideal for building automation systems and factory control panels. Easy to install with DIN-rail mounting, it supports your applications with reliable operation across temperatures from -25°C to +70°C. Order today for quick delivery and premium quality engineering designed to meet international safety standards.
Get Traco Power TBL090112 today—engineered for reliable performance in automation projects and industrial environments.
Frequently Asked Questions
Where can I buy TRACO POWER TBL090112?
You can click on the BUY or RFQ button to purchase TBL090112 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TBL090112?
You can download the TBL090112 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TBL090112?
TRACO POWER
