TRACO POWER TCK047 Power Inductor
The TCK-047 is a high-performance inductor designed for power electronics and filtering applications. It features a 10 pH inductance with a 20% tolerance at 1 KHz/1 V, and a maximum impedance of 100 mOhm. The component operates reliably from -40°C to +125°C, supports a rated current of 1.44 A, and has compact outline dimensions suitable for PCB mounting. Its impedance curve and precise dimensions make it ideal for power supply circuits and electronic filtering in various industrial and consumer electronics.
TRACO POWER TCK047 Power Inductor Specifications:
- Inductance: 10 pH 20% (at 1 KHz/1 V)
- Impedance (DCR): 100 mOhm max.
- Rated Current: 1.44 A max.
- Operating Temperature: -40°C to +125°C
- Outline Dimensions: A 5.2 +0.5 mm, B 5.8 +0.5 mm, C 4.5 +0.6 mm, D 1.3 mm typ., E 5.5 mm, F 2.15 mm, G 1.7 mm
- PCB Pattern: F, E, G
- Impedance Curve: Provided for filtering characteristics
- Material: Ceramic core with copper wire windings
- Application: Power filtering, electronic circuits, industrial and consumer electronics
- Brand: Traco Power
- Model: TCK-047
Buy the Traco Power Series TCK-047 Inductor: 10 pH Power Filter Component
Enhance your electronic projects with the Traco Power Series TCK-047 inductor, offering 10 pH inductance, 1.44 A rated current, and broad temperature support from -40°C to +125°C. Its compact dimensions and low impedance make it perfect for power filtering, noise reduction, and electronic circuit stability. Ideal for industrial, consumer, and power supply applications, this high-quality inductor ensures durable performance and reliable operation in demanding environments. Purchase online now for fast delivery and trusted quality.
Order your Traco Power Series TCK-047 inductor today and enhance your power circuits with reliable filtering components.
Frequently Asked Questions
Where can I buy TRACO POWER TCK047?
You can click on the BUY or RFQ button to purchase TCK047 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TCK047?
You can download the TCK047 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TCK047?
TRACO POWER
