TRACO POWER TEL22411 Industrial Power Converter
The TEL 2 Series DC/DC converters provide a compact, high-reliability solution for industrial and electronic applications. Designed in a low profile DIN-16 package, these 2-watt isolated converters feature a wide input range, precise regulated outputs, and high efficiency with low ripple. They are robust, with protections against short circuits and reverse polarity, and operate reliably from -40°C to +75°C without derating. Compliant with RoHS standards, these converters are ideal for space-constrained environments requiring stable power supply solutions in various industrial electronics. They are suitable for applications demanding low noise and high electrical isolation.
TRACO POWER TEL22411 Industrial Power Converter Specifications:
- Input voltage: 5 VDC, 12 VDC, 24 VDC, 48 VDC with models available for each range
- Output voltage: 3.3 VDC, 5 VDC, 12 VDC, 15 VDC, 18-36 VDC, 36-72 VDC, 48 VDC, +5 VDC, +12 VDC, +15 VDC
- Maximum output current: 500 mA for 3.3 V models, 400 mA for 5 V models, 165 mA for 12 V models, 135 mA for 15 V models
- Efficiency: up to 81%, typical adjustable regulation within +2% maximum
- Isolation voltage: 1500 VDC, isolation capacitance: up to 250 pF, isolation resistance: > 1000 MΩ
- Operating temperature: -40°C to +75°C, humidity: 95% non-condensing
- Dimensions: approximately 16 mm x 10 mm x 12 mm, weight: 51 g, housing: non-conductive FR4 material
- Features: Short-circuit protection, low ripple (50 mV PK-PK), and automatic restart on short circuit
- Standards: UL, cUL, IEC 60950, EN 60950, CSA 60950-1-03, RoHS compliant
- MTBF: > 1.2 million hours based on MIL HDBK-217F at +25°C
- Input transient overvoltage: up to 100 V max for 100 ms, reverse polarity protection: 1 A max
Buy the Buy TracoPower TEL 2 Series Power Converter Part Number TEL22411 Online
Purchase the TracoPower TEL 2 Series power converter TEL22411 online now to enjoy a compact, highly reliable power supply with wide input ranges, precise output regulation, and robust protections. Designed for industrial electronics, these 2-watt DC/DC converters feature high efficiency, low ripple, and excellent isolation, making them ideal for demanding applications. With compliance to safety standards and a MTBF of over 1.2 million hours, they ensure long-term durability. Order today to enhance your equipment with dependable, space-efficient power solutions.
Order your TracoPower TEL 2 Series power converter TEL22411 today and ensure reliable, space-saving power for your critical industrial projects.
Frequently Asked Questions
Where can I buy TRACO POWER TEL22411?
You can click on the BUY or RFQ button to purchase TEL22411 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEL22411?
You can download the TEL22411 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEL22411?
TRACO POWER
