TRACO POWER TEN31211 Industrial DC/DC Converter
The POWER TEN series of DC/DC converters offers a reliable solution for industrial and communication systems, providing high efficiency up to 84% and extended operating temperature ranges from -40°C to +85°C. These compact, full SMD design units feature internal filtering according to EN 55022, FCC level A standards, and include short circuit and reverse voltage protection. With wide input voltage ranges and high MTBF over 1.1 million hours, they are suitable for a broad array of applications requiring stable, isolated power supplies. Proven durability and a 3-year warranty ensure dependable performance in demanding environments.
TRACO POWER TEN31211 Industrial DC/DC Converter Specifications:
- Input voltage range: 3.3 VDC to 48 VDC with various models
- Output voltage options: 5 VDC, 12 VDC, 15 VDC, 24 VDC, 36 VDC, 72 VDC
- Output current: up to 600 mA depending on model
- Efficiency: up to 84%
- Wide operating temperature: -40°C to +85°C
- Isolation voltage: 1500 VDC
- Ripple and noise: 60 mVpk-pk at 20 MHz bandwidth
- Switching frequency: 300 kHz (typical)
- MTBF: >1.1 million hours
- Dimensions: Compact epoxy potting case, approximately 22.86 mm x 16 mm x 10.2 mm
- Soldering temperature: max 265°C for 10 seconds
- Regulation: <0.5% variation over input and load changes
- Short circuit protection: indefinite, automatic recovery
- Reliability standards: cUL/UL 60950-1
Buy the Buy TRACOPOWER DC/DC Converter Part Number TEN31211 Online
Purchase the TRACOPOWER Series TEN31211 high-efficiency DC/DC converter online today for your industrial and communication systems. Featuring wide input voltage ranges from 3.3 V to 48 V, this compact unit offers up to 84% efficiency, internal EN 55022 filtered design, and full SMD construction. It supports operating temperatures from -40°C to +85°C, has a 1500 VDC isolation, and includes short circuit, reverse voltage protection, and a 3-year warranty. Reliable, durable, and essential for stable, isolated power in demanding environments.
Order your TRACOPOWER Series TEN31211 industrial high-efficiency DC/DC converter today and ensure reliable, stable power for your demanding projects.
