TRACO POWER TMR0522 DC/DC Power Converter
The TMR-2 series comprises compact, high-efficiency isolated 2W DC/DC converters with regulated outputs, featuring wide 2:1 input voltage ranges, SIP-8 footprint, and full SMD design. Operable from -40°C to +85°C, they include remote On/Off control, short circuit protection, and optional dual or single outputs. Ideal for space-critical applications such as communication, instrumentation, and industrial electronics, these converters comply with UL, RoHS, and EN standards, offering reliable performance in demanding environments with excellent load and line regulation.
TRACO POWER TMR0522 DC/DC Power Converter Specifications:
- Input voltage range: 5 VDC to 48 VDC with surge voltage up to 100 V
- Output voltages: 3.3 V, 5 V, 12 V, 15 V with max currents from 65 mA to 500 mA
- Efficiency: 76% to 84% depending on model
- Operating temperature: -40°C to +85°C
- Isolation voltage: 1600 VDC
- Isolation capacitance: 200 pF
- Short circuit protection: Continuous, automatic recovery
- Dimensions: 21.8 mm x 10.0 mm x 12.6 mm, weight 48 g
- Switching frequency: 100 kHz to 650 kHz
- UL/IEC safety compliance, RoHS and Reach compliant
- Full SMD design, potting with UL-rated silicone
- Remote On/Off control: Open or high impedance for ON, 2-4 mA via resistor for OFF
Buy the Buy TracoPower TMR0522 Part Number TMR0522 Online
Purchase the TracoPower TMR0522 DC/DC power converter online today to enjoy reliable 2W power in a compact design. This high-efficiency module offers wide input voltage compatibility, excellent load regulation, and safety features including short circuit protection and remote On/Off control. Perfect for space-constrained applications in industrial, communication, and instrumentation sectors, it provides proven durability, UL and RoHS compliance, and a 3-year warranty. Order now for fast delivery and keep your electronic systems running smoothly and efficiently.
Get TracoPower TMR0522 today—compact, high-efficiency power solution with remote On/Off and full safety compliance.
Frequently Asked Questions
Where can I buy TRACO POWER TMR0522?
You can click on the BUY or RFQ button to purchase TMR0522 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TMR0522?
You can download the TMR0522 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TMR0522?
TRACO POWER
