TRACO POWER TEN62410N DC-DC Converter
The TEN 6-2410N from TracoPower is a high-performance, single-output 6W DC-DC converter housed in a 24-pin DIP package. It features overload protection, internal filtering compliant with EN55022 Class A standards, no minimum load requirement, and high efficiency. With a wide input voltage range of 18V to 36V DC, it provides a fixed 3.3V output capable of delivering up to 1200mA. Its efficiency is approximately 77%, and it offers 1500VDC I/O isolation, ±2% regulation accuracy, and a switching frequency of 330kHz. Suitable for industrial, communication, and computing devices, it operates from -40°C to +85°C, comes in a UL 94V-0 plastic case, and supports surge voltages up to 50V for 1 second. Its dimensions are 20.3mm x 10.2mm x 31.8mm, making it ideal for cost-effective power management solutions.
TRACO POWER TEN62410N DC-DC Converter Specifications:
- Input Voltage Range: 18V to 36V DC
- Output Voltage: 3.3V DC
- Output Current: 1200mA
- Efficiency: 77%
- Isolation Voltage: 1500VDC
- Switching Frequency: 330kHz
- Input Current at Full Load: 440mA (12V models), 300mA (24V models), 150mA (48V models)
- No Minimum Load Required
- Operating Temperature: -40°C to +85°C
- Protection: Overload, Short Circuit (automatic recovery)
- Case Material: UL 94V-0 rated plastic
- Dimensions: 20.3mm x 10.2mm x 31.8mm
- Surge Voltage: 50V max for 1 sec
- Certifications: UL/cUL 60950-1, IEC/EN 60950-1
Buy the TracoPower TEN62410N – Reliable DC-DC Converter for Industrial Applications
Enhance your power systems with the TracoPower TEN62410N DC-DC converter, offering high efficiency, wide input range, and robust isolation. Designed for industrial, communication, and computing applications, it ensures stable voltage regulation, built-in protection, and compliance with safety standards. Its compact DIP-24 package allows easy integration into various equipment, while the no minimum load requirement simplifies deployment. Perfect for applications demanding reliable operation from -40°C to +85°C, this converter guarantees long-term performance and safety, making it the ideal choice for demanding environments.
Buy TracoPower TEN62410N now and experience unmatched reliability and performance in your power management systems.
Frequently Asked Questions
Where can I buy TRACO POWER TEN62410N?
You can click on the BUY or RFQ button to purchase TEN62410N from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN62410N?
You can download the TEN62410N datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN62410N?
TRACO POWER
