TRACO POWER TES10522 DC/DC Converter
The TES 1 Series 1 Watt DC/DC converters are compact, high-efficiency devices suitable for isolating voltages in various electronic applications. Featuring a small SMD package, they provide up to 80% efficiency, operate within -40°C to +90°C, and support lead-free reflow soldering. These converters have input voltages of 5, 12, and 24 VDC, with multiple output options including 5V, 12V, 15V, and 24V. They are ideal for noise reduction, ground loop elimination, and digital interface isolation, meeting industrial safety standards with 1500 VDC isolation and low ripple noise.
TRACO POWER TES10522 DC/DC Converter Specifications:
- Input Voltage: 5V, 12V, 24V DC
- Output Voltage: 3.3V, 5V, 9V, 12V, 15V, 24V DC
- Output Current Max: 435 mA
- Efficiency: up to 80%
- Isolation Voltage: 1500 VDC
- Operating Temperature Range: -40°C to +90°C
- Case Material: UL94V-0 rated plastic
- Weight: Single output models: 1.7 g, Dual output models: 2.0 g
- Lead-free reflow solder process compatible
- Peak package temperature: 245°C
- Humidity: up to 95% RH non-condensing
- Short circuit protection: Limited 0.5 sec.
- Ripple and Noise (20 MHz BW): 120 mVpp max
- Switching Frequency: 100 kHz typical
- Isolation Resistance: >1GΩ
- MTBF: >2,000,000 hours
Buy the Traco Power Series TES: DC/DC Converter 1 Watt: TES10522
Purchase the Traco Power TES10522 DC/DC converter online to ensure high efficiency, robust voltage isolation, and compact size ideal for industrial and electronic applications. Designed to operate between -40°C and +90°C, it offers 1500 VDC isolation, multiple input/output voltage options, and compliance with lead-free reflow soldering. Perfect for reducing noise, eliminating ground loops, and providing reliable power conversion in distributed systems. With high MTBF and certification standards, order now for fast delivery and performance assurance.
Get Traco Power TES10522 today—built for high efficiency and reliable voltage isolation in compact designs.
Frequently Asked Questions
Where can I buy TRACO POWER TES10522?
You can click on the BUY or RFQ button to purchase TES10522 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TES10522?
You can download the TES10522 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TES10522?
TRACO POWER
